HIKVISION

DS-1273ZJ-135(Black)  Wall Mount      Features   Aluminum alloy with surface spray treatment   Internal cable routing design   Cap design facilitates installation  Dimension  120 mm (4.72" )  85.7 mm (3.37" )  183  .5  mm  (7  .22  " )  158  mm  (6  .22  " )  83.5 mm (3.29" )  46 mm (1.81" )  6-M4 Depth:  8 mm (0.31" )  83  .5  mm  (3  .29  " )  230 mm (9.06" )      Available Model  DS-1273ZJ-135(Black)  Parameter  Model    Parameters  DS-1273ZJ-135(Black)  Wall Mount  Appearance Black  Material Aluminum Alloy  Dimension 120 mm x 183.5 mm x 230 mm (4.72" x 7.22" x 9.06")  Weight 870 g (1.92 lb.)  Notes   The mount should be installed on the flat surface.   The wall must be capable of supporting at least 3 times as much as the total weight of the camera, and the  mount.   The maximum load capacity of the mount is 4.5 kg (9.9 lb.)....

Warranty: 36 mon.

Datasheet

DS-1273ZJ-140B      DS-2CC51xxP(N) Wall Mounting Bracket for  Dome Camera (with Junction box)  Features:   Aluminum alloy material with surface spray  treatment   The outlet hole makes the feature looks better   Better water proof design   Convenient installation coordinating with lower  bowl  Dimension:      Order Model:  DS-1273ZJ-140B  Parameter:  Model    Parameters  DS-1273ZJ-140B  DS-2CC51xxP(N) Wall Mounting Bracket for  Dome Camera (with Junction box)  Appearance Hikvision White  Range of  Application  Suitable for DS-2CC51xxP(N) dome camera wall  mounting  Material Aluminum Alloy  Dimension Φ140x182x120mm  Weight 1488g  Notice:   The bracket is for DS-2CC51xxP(N)-VF dome camera   Pay attention to the color matching when select bracket   The bracket should be installed on flat wall   The wall must be capable of supporting over 3 times as  much as the total weight of the camera and the mount   The maximum load capacity of the bracket is 4.5KG  Model Suitable:  DS-2CC51xxP(N)-VP  DS-2CC51xxP(N)-VPIR  D...

Warranty: 36 mon.

Datasheet

DS-1273ZJ-135      Wall Mounting Bracket for Dome Camera  Features:   Aluminum alloy material with surface spray  treatment   Design of cable entrance hole   Better water proof design   Convenient installation coordinating with adaptor  cap  Dimension:    Order Model:  DS-1273ZJ-135  Parameter:  Model    Parameters  DS-1273ZJ-135  Wall Mounting Bracket for  Dome Camera  Appearance Hikvision White  Range of  Application  Suitable for dome camera wall mounting  Material Aluminum Alloy  Dimension Φ136x183.5x230mm  Weight 704g  Notice:   The bracket should be installed on flat wall   The wall must be capable of supporting over 3 times as  much as the total weight of the camera and the mount.   The maximum load capacity of the bracket is 4.5KG  Model Suitable:  DS-2CC52X1P(N)-VP, DS-2CC52X1P(N)-AVPIR2,  DS-2CD2712F-I(S), DS-2CD2732F-I(S)  Installation Step:  ① Choose appropriate wall  to install the bracket and  thread the cable  ② Fix adaptor to bracket and  thread the cable  ③ Screw up and complete  the fixation...

Warning! Product withdrawn from production!

Replacement product: DS-1473ZJ-155

Replacement product code: 302701859

Warranty: 36 mon.

Datasheet

DS-1273ZJ-155-Black  Wall Mount      Feature   Alloy with surface spray treatment   The cap facilitates the installation   Adopts waterproof design  Dimension  83.5 mm  (3.29'')46 mm  (1.81'')  83  .5  mm  (3  .29  '')  6-M4  depth 8 mm (0.31'')  158  mm  (6  .22  '')  183  mm  (7  .20  '')  85.7 mm (3.37'')  120 mm (4.72'')  240 mm (9.45'')      Available Model  DS-1273ZJ-155-Black  Parameter  Model    Parameters  DS-1273ZJ-155-Black  Wall Mount  Appearance Hikvision Black  Material Alloy  Dimension Φ 155 mm x 183.5 mm x 240 mm (Φ 6.10" x 7.20" x 9.45")  Weight Approx. 760 g (1.68 lb.)  Note   The mount should be installed on the flat surface.   The wall should be capable of supporting at least 3 times as much as the total weight of the camera and the mount.   The maximum load capacity of the mount is 3 kg (6.6 lb.)....

Warning! Product withdrawn from production!

Warranty: 36 mon.

Datasheet

DS-1273ZJ-155  FEATURES:  Ÿ Aluminum alloy material with surface spray treatment  Ÿ The cap facilities the installation  Ÿ Better water proof design    SPEC  Parameters Wall mount  Colour Hik White  Feature Suitable for dome camera  Material Aluminum Alloy  Dimension 155 x 183.5 x 240mm  Weight 650g  Ÿ Pay attention to the colour matching when select bracket  Ÿ The bracket should be installed on a flat wall  Ÿ The wall must be capable of supporting over 3 times as   much as the total weight of the camera and the mount  Ÿ The maximum load capacity of the bracket is 3kg  83.5  46  8  3  .5  Ø155  15  8  18  3  .5  85.7  120  unit: mm  240...

Warning! Product withdrawn from production!

Replacement product: DS-1473ZJ-155B

Replacement product code: 302701980

Warranty: 36 mon.

Datasheet

DS-1273ZJ-160B  Wall Mounting Bracket for Dome Camera  (With junction box)  Features:   Aluminum alloy material with surface spray  treatment   Design with cable entry hole   Better water proof design   Convenient installation coordinating with cap  Dimension:      Order Model:  DS-1273ZJ-160B  Parameter:  Model    Parameters  DS-1273ZJ-160B  Wall Mounting Bracket for  Dome Camera(with junction box)  Appearance Hikvision White  Range of  Application  Suitable for dome camera wall mounting  Material Aluminum Alloy  Dimension Φ160x243x303mm  Weight 1630g  Notice:   The bracket is for dome camera   Pay attention to color matching   The bracket should be installed on flat wall   The wall must be capable of supporting over 3 times as  much as the total weight of the camera and the mount.   The maximum load capacity of the bracket is 4.5KG    Model Suitable:  DS-2CD72XXF-E(I)Z(H)(S),DS-2CD72X3PF-E(I)Z(H)(S),DS-2CD72X3NF-E(I)Z(H)(S),DS-2CD7293PFWD-E(I)Z(H)(S),DS-2CD7293NFWD-  E(I)Z(H)(S),DS-2CD72X4FWD-E(I)Z(H)(S),DS-2CD4312F(WD)-(I)(Z)(H)(S),DS-2CD4324F-(I)(Z)(H)(S),DS-2CD4332FWD-(I)(Z)(...

Warning! Product withdrawn from production!

Warranty: 36 mon.

Datasheet

DS-1273ZJ-DM26-B  Wall Mount with Junction Box  For Dome Camera    Features:   Aluminum alloy material with surface spray  treatment   Waterproof design   Cable hole on bracket makes the feature  better   Design of cap is for convenient wiring  Dimension:              Order Model:  DS-1273ZJ-DM26-B  Parameter:  Model    Parameters  DS-1273ZJ-DM26-B  Wall Mount with Junction Box  For Dome Camera  Appearance Hikvision White  Material Aluminum Alloy  Dimension 310x260x185mm  Weight 2050g  Notice:   The bracket should be installed on flat wall   Waterproof rubber is necessary for outdoor application   The wall must be capable of supporting over 3 times as  much as the total weight of the camera and the mount   The maximum load capacity of the bracket is 4.5KG    Note: The actual bracket may vary from the picture above.  314.5  φ184.9  260...

Warning! Product withdrawn from production!

Warranty: 36 mon.

Datasheet

DS-1273ZJ-DM26-B  Wall Mount with Junction Box  For Dome Camera    Features:   Aluminum alloy material with surface spray  treatment   Waterproof design   Cable hole on bracket makes the feature  better   Design of cap is for convenient wiring  Dimension:              Order Model:  DS-1273ZJ-DM26-B  Parameter:  Model    Parameters  DS-1273ZJ-DM26-B  Wall Mount with Junction Box  For Dome Camera  Appearance Hikvision White  Material Aluminum Alloy  Dimension 310x260x185mm  Weight 2050g  Notice:   The bracket should be installed on flat wall   Waterproof rubber is necessary for outdoor application   The wall must be capable of supporting over 3 times as  much as the total weight of the camera and the mount   The maximum load capacity of the bracket is 4.5KG    Note: The actual bracket may vary from the picture above.  314.5  φ184.9  260...

Warning! Product withdrawn from production!

Warranty: 36 mon.

Datasheet
