HIKVISION

DS-KD3002-VM  Video Intercom Metal Door Station    Key Features    Basic Functions   Video intercom function   Access control function   Issues cards via door station, up to Max. 2500 cards, via outer door station, up to 50000 cards  (This function will be invalid if the card has been issued via the client.)   Card readers supported   Self-adaptive visible light supplement  Video/Audio Functions   HD video surveillance with high performance CMOS   Noise suppression and echo cancellation   H.264 video compression   Low illumination  Remote Control   Remote unlocking via the client or the app   Remotely answering the call via the client or the app  Alarm Functions   Tampering alarm and door magnetic alarm supported   Auto-uploads alarm messages to master station or the client once the duress code is entered to  open the door  Additional Features   Message notification function   Auto-uploads captured pictures to FTP or the client while unlocking the door                Model DS-KD3002-VM  System  parameters  Processor High-Performance Embedded SOC Processor  Operation system Embedded Linux Operation System  Video ...

Warning! Product withdrawn from production!

Warranty: 24 mon.

Datasheet

DS-KD8002-2A    DS-KD8002-VM         Video intercom function   HD video surveillance (Max. resolution 1280 x 720@25fps, WDR, 120° wide angle)   Self-adaptive light supplement   Access control function   Activating card via local station function (This function will be invalid if the card has been  activated via iVMS-4200)   Auto-uploading captured pictures to FTP or iVMS-4200 Client while unlocking the door   Door magnetic alarm and tamper-proof alarm function   Noise suppression and echo cancellation   Remote upgrade, batch setting, upgrade via USB flash disk functions    Metal Door Station    MAIN FEATURES    DS-KD8002-VM    AVAILABLE MODELS      Spec of DS-KD8002-VM Door Station www.hikvision.com  2                                  Model  Parameters  DS-KD8002-VM  System Parameters  Processor High-performance Embedded SOC Processor  Operation System Embedded Linux OS  Video Parameters  Camera  CMOS Low Illumination 1.3 MP HD Colorful  Camera  Video Compression  ...

Warning! Product withdrawn from production!

Warranty: 24 mon.

Datasheet

DS-KD8003-IME1  Video Intercom Module Door Station    Key Feature   2 MP HD video intercom function   Access control function   Noise suppression and echo cancellation   H.264 video compression   Low illumination   Tampering alarm supported   Fisheye camera with IR supplement light   Supports sub-modules’ access (max. 8)   Nametag customization   Easy to and extend                            Model DS-KD8003-IME1  System  parameters  Processor Embedded MCU Processor  Operation system Embedded Linux Operation System  Operation method Physical Button  Video  parameters  Camera Low Illumination 2 MP HD IR Camera  Video compression  standard  H.264  Resolution  Main Stream: 1920 x 1080  Sub Stream: 720 x 480  BLC Supported  DNR Supported  WDR Supported  Anti-flicker 50 Hz, 60 Hz  Field of View Horizontal：180° Vertical：96°  Audio  parameters  Audio input Built-in Omnidirectional Microphone  Audio output Built-in Loudspeaker(More than 85 dB within 20 cm )  Audio compression  standard  G.711 U  Audio compression rate 64 Kbps  Audio quality Noise Suppression and ...

Warning! Product withdrawn from production!

Replacement product: DS-KD8003-IME1(B)

Replacement product code: 305303873

Warranty: 24 mon.

Datasheet

DS-KD8003-IME1  Video Intercom Module Door Station    Key Feature   2 MP HD video intercom function   Access control function   Noise suppression and echo cancellation   H.264 video compression   Low illumination   Tampering alarm supported   Fisheye camera with IR supplement light   Supports sub-modules’ access (max. 8)   Nametag customization   Easy to and extend                            Model DS-KD8003-IME1  System  parameters  Processor Embedded MCU Processor  Operation system Embedded Linux Operation System  Operation method Physical Button  Video  parameters  Camera Low Illumination 2 MP HD IR Camera  Video compression  standard  H.264  Resolution  Main Stream: 1920 x 1080  Sub Stream: 720 x 480  BLC Supported  DNR Supported  WDR Supported  Anti-flicker 50 Hz, 60 Hz  Field of View Horizontal：180° Vertical：96°  Audio  parameters  Audio input Built-in Omnidirectional Microphone  Audio output Built-in Loudspeaker(More than 85 dB within 20 cm )  Audio compression  standard  G.711 U  Audio compression rate 64 Kbps  Audio quality Noise Suppression and ...

Warning! Product withdrawn from production!

Replacement product: DS-KD8003-IME1(B)/Flush

Replacement product code: 305303874

Warranty: 24 mon.

Datasheet

DS-KD8003-IME1  Video Intercom Module Door Station    Key Feature   2 MP HD video intercom function   Access control function   Noise suppression and echo cancellation   H.264 video compression   Low illumination   Tampering alarm supported   Fisheye camera with IR supplement light   Supports sub-modules’ access (max. 8)   Nametag customization   Easy to and extend                            Model DS-KD8003-IME1  System  parameters  Processor Embedded MCU Processor  Operation system Embedded Linux Operation System  Operation method Physical Button  Video  parameters  Camera Low Illumination 2 MP HD IR Camera  Video compression  standard  H.264  Resolution  Main Stream: 1920 x 1080  Sub Stream: 720 x 480  BLC Supported  DNR Supported  WDR Supported  Anti-flicker 50 Hz, 60 Hz  Field of View Horizontal：180° Vertical：96°  Audio  parameters  Audio input Built-in Omnidirectional Microphone  Audio output Built-in Loudspeaker(More than 85 dB within 20 cm )  Audio compression  standard  G.711 U  Audio compression rate 64 Kbps  Audio quality Noise Suppression and ...

Warning! Product withdrawn from production!

Replacement product: DS-KD8003-IME1(B)/Surface

Replacement product code: 305303872

Warranty: 24 mon.

Datasheet

All IP Video Intercom Master Station            DS-KD8102-V         Video intercom function   HD video surveillance (Max. resolution 1280x720@30fps, WDR, 120° wide angle)   Self-adaptive light supplement   Access control function   Activating card via local station function (This function will be invalid if the card has been  activated via iVMS-4200)   Auto-uploading captured pictures to FTP or iVMS-4200 Client while unlocking the door   Door magnetic alarm and tamper-proof alarm function   Noise suppression and echo cancellation   IR detection   Remote upgrade, batch setting, upgrade via USB flash disk functions    Door Station    MAIN FEATURES    DS-KD8102-V    AVAILABLE MODELS      Spec of DS-KD8102-V Door Station www.hikvision.com  2                                  Model  Parameters  DS-KD8102-V  System  Parameters  Processor High-Performance Embedded SOC Processor  Operation System Embedded Linux OS  Video Parameters  Camera  CMOS Low Illumi...

Warning! Product withdrawn from production!

Warranty: 24 mon.

Datasheet

DS-KD9613-FE6  Video Intercom Face Recognition Door Station            Key Feature  * 10-inch capacitive touch screen  * Publishes and displays the image on the screen with  resolution: 600 x 1024p  * 2 x 2MP HD camera, ultra-wide angel lens  * Deep learning algorithm: Face anti-sproofing  * Unlocks door by face recognition  * Face capacity: 3000  * Noise suppression and echo cancellation  * Stand-alone operation: Card enrollment, fingerprint adding,  and face adding locally  * Protection level: IP65    Approval  CE-EMC  a. EN 55032:2015  b. EN 61000-3-2:2014  c. EN 61000-3-3:2013  d. EN 50130-4:2011 +A1:2014  CE-LVD  EN 60950-1:2006 + A11:2009 + A1:2010 +  A12:2011 + A2:2013  ROHS 2011/65/EU  REACH Regulation (EC) No 1907/2006  WEEE 2012/19/EU          Specification  System parameters  Operation  system  Embedded Linux operation system  Operation  method  Capacitive touch screen  Display parameters  Display screen 10-inch colorful LCD  Display  resolution  600 x 1024  Video Parameters  Camera 2 x 2 MP HD IR camera  Night vision Low illumination, IR supplement lights  ...

Warning! Product withdrawn from production!

Warranty: 24 mon.

Datasheet

DS-KD9613-FE6  Video Intercom Face Recognition Door Station            Key Feature  * 10-inch capacitive touch screen  * Publishes and displays the image on the screen with  resolution: 600 x 1024p  * 2 x 2MP HD camera, ultra-wide angel lens  * Deep learning algorithm: Face anti-sproofing  * Unlocks door by face recognition  * Face capacity: 3000  * Noise suppression and echo cancellation  * Stand-alone operation: Card enrollment, fingerprint adding,  and face adding locally  * Protection level: IP65    Approval  CE-EMC  a. EN 55032:2015  b. EN 61000-3-2:2014  c. EN 61000-3-3:2013  d. EN 50130-4:2011 +A1:2014  CE-LVD  EN 60950-1:2006 + A11:2009 + A1:2010 +  A12:2011 + A2:2013  ROHS 2011/65/EU  REACH Regulation (EC) No 1907/2006  WEEE 2012/19/EU          Specification  System parameters  Operation  system  Embedded Linux operation system  Operation  method  Capacitive touch screen  Display parameters  Display screen 10-inch colorful LCD  Display  resolution  600 x 1024  Video Parameters  Camera 2 x 2 MP HD IR camera  Night vision Low illumination, IR supplement lights  ...

Warning! Product withdrawn from production!

Warranty: 24 mon.

Datasheet

1            DS-KEM125        Model DS-KEM125  Card Property Thin Card  Sensing Frequency 125KHz +/- 6KHz  Data Format EM-4100  Memory Capacity 64 bit  Function Read  Sensing Distance 15cm  Temperature -20 ℃ -- ＋ 75 ℃  Material PVC  Color White  Dimension 85.5mm x 54mm x 0.8mm  Weight ＜ 5.6g                          DS-KEM125    EM Card    SPECIFICATIONS    AVAILABLE MODEL...

Warranty: 24 mon.

Datasheet

DS-KH2220  Video Intercom Indoor Station    Key Features   Hands-free video intercom communication   Supports three indoor stations in the intercom system   Supports monitoring the door station and the external  analog camera   Remote unlocking   Wall mounting supported   Convenient installation with/without the junction box  Typical Application        Door Station  Indoor Station 2  Indoor Station 3  Indoor Station 1  Analog Camera 3  Analog Camera 2  Analog Camera 1    Lock  Four-Core Cable    Block to BNC Cable  Electric Lock  Connection Cable                      Model DS-KH2220  Display  parameters  Display screen 7-Inch Colorful TFT LCD  Display  resolution  800 x 480  Operation  method  Physical Button  Audio  parameters  Audio input Built-in Omnidirectional Microphone  Audio output Built-in Loudspeaker  Audio quality Noise Suppression and Echo Cancellation  Device  interfaces  Four-wire  interface  4 Four-Wire Interfaces  1-ch Video Input, 1-ch Audio Input/Output, 1-ch Power  Supply, 1-ch Grounding  General  Power supply 12 VDC  Po...

Warning! Product withdrawn from production!

Warranty: 24 mon.

Datasheet

DS-KH2220-S  Video Intercom Indoor Station    Key Features   Hands-free video intercom communication   Supports three indoor stations simultaneously  in the intercom system   Supports monitoring the door station and the external  analog camera   Supports captured image playback   Remote unlocking   Convenient installation and easy operation  Typical Application          Door Station  Indoor Station 2  Indoor Station 3  Indoor Station 1  Analog Camera 3  Analog Camera 2  Analog Camera 1    Lock  Four-Core Cable    Block to BNC Cable  Electric Lock  Connection Cable                            Model DS-KH2220-S  Display  parameters  Display screen 7-Inch Colorful TFT LCD  Display  resolution  800 x 480  Operation  method  Physical Button  Audio  parameters  Audio input Built-in Omnidirectional Microphone  Audio output Built-in Loudspeaker  Audio quality Noise Suppression and Echo Cancellation  Device  interfaces  Four-wire  interface  4 Four-Wire Interfaces  1-ch Video Input, 1-ch Audio Input/Output, 1-ch Power  Supply, 1-ch Grounding

Warning! Product withdrawn from production!

Warranty: 24 mon.

Datasheet

DS-KH6210-L  Video Intercom Indoor Station with 7-inch Screen    Key Features  Basic Functions   Hands-free audiovisual communication with the door  station and the master station in the intercom system   Panic call supported   2-ch zone alarm supported   Supports monitoring door stations and external cameras   Remote unlocking via the client software   High-performance embedded SOC processor  Video/Audio Functions   HD video surveillance with high performance CMOS   7-inch colorful FTF LCD with resolution 800 x 480   Noise suppression and echo cancellation   H.264 video compression  Alarm Functions   2-ch alarm input sensors supported   Auto-uploads alarm messages to the master station, or  the client software once the alarm sensor is triggered  Additional Features   Community notice supported   Convenient installation and easy operation  Typical Application  Switch  Client Software  Center Master Station  (Master Station)  Network Cable  Optical Fiber  Door Station  Resident 2       Building      IPC   Master Station  in Guard's Room  Outer Door Station  Switch  Resident 2    One Resident      ...

Warning! Product withdrawn from production!

Warranty: 24 mon.

Datasheet

DS-KH6310-W  DS-KH6310         Video intercom function   Remote unlocking function   Resident-to-resident audio call   Live view of HD video   Voice message function   Auto-respond and no disturbing mode   Noise suppression and echo cancellation   8-ch zone alarm and SOS calling function   Community notice   Convenient installation with the bracket, batch setting, and power over video/audio  distributor (DS-KAD606, DS-KAD612)    Indoor Station    MAIN FEATURES    DS-KH6310-W/DS-KH6310    AVAILABLE MODELS      Spec of DS-KH6310-W/DS-KH6310 Indoor Station www.hikvision.com  2                                  Model  Parameters  DS-KH6310-W DS-KH6310  Video Intercom Indoor Station with 7-Inch Touch Screen  System  Parameters  Processor High-Performance Embedded SOC Processor  Operation System Embedded Linux Operation System  Display  Parameters  Display Screen 7-Inch Colorful TFT LCD  Display Resolution 800 x 480  Operation Method Capacitive Touch Screen, Physical Key  Operation Interface ...

Warning! Product withdrawn from production!

Warranty: 24 mon.

Datasheet

DS-KH6310-W  DS-KH6310         Video intercom function   Remote unlocking function   Resident-to-resident audio call   Live view of HD video   Voice message function   Auto-respond and no disturbing mode   Noise suppression and echo cancellation   8-ch zone alarm and SOS calling function   Community notice   Convenient installation with the bracket, batch setting, and power over video/audio  distributor (DS-KAD606, DS-KAD612)    Indoor Station    MAIN FEATURES    DS-KH6310-W/DS-KH6310    AVAILABLE MODELS      Spec of DS-KH6310-W/DS-KH6310 Indoor Station www.hikvision.com  2                                  Model  Parameters  DS-KH6310-W DS-KH6310  Video Intercom Indoor Station with 7-Inch Touch Screen  System  Parameters  Processor High-Performance Embedded SOC Processor  Operation System Embedded Linux Operation System  Display  Parameters  Display Screen 7-Inch Colorful TFT LCD  Display Resolution 800 x 480  Operation Method Capacitive Touch Screen, Physical Key  Operation Interface ...

Warranty: 24 mon.

Datasheet

DS-KH6310-WL  Video Intercom Indoor Station with 7-inch Touch Screen    Key Features  Basic Functions   Hands-free audiovisual communication with the door  station and the master station in the intercom system   Panic call supported   2-ch zone alarm supported   Supports monitoring door stations and external cameras   Remote unlocking via the client software or the app   High-performance embedded SOC processor  Video/Audio Functions   HD video surveillance with high performance CMOS   7-inch colorful FTF LCD with resolution 800 x 480   Capacitive touch screen and physical buttons   Noise suppression and echo cancellation   H.264 video compression  Alarm Functions   2-ch alarm input sensors supported   Auto-uploads alarm messages to the master station  the client software, or the app once the alarm  sensor is triggered  Additional Features   Community notice supported   Convenient installation and easy operation  Typical Application  Switch  Client Software  Center Master Station  (Master Station)  Network Cable  Optical Fiber  Door Station  Resident 2       Building      IPC   Master Station  in Guard's Room ...

Warning! Product withdrawn from production!

Warranty: 24 mon.

Datasheet
