DS-1203ZJ(-S)  Pendent Mounting Bracket Indoor  Features:   Die casting aluminum   Universal control of angle   Monitoring scene adjustment  Dimension:    Order model:  DS-1203ZJ DS-1203ZJ-S  Parameters:  Model  Parameter  DS-1203ZJ DS-1203ZJ-S  Pendent Mounting Bracket Indoor  Color Hik white Silver  Feature  Suitable for box, bullet and zoom camera  pendent mounting  Angle Horizontal:360°; Vertical:0~90°  Dimension 70.4x84x200.5mm  Weight 220g  Notice:   Pay attention to color matching   The bracket should be installed on the flat surface of a  wall   The wall must be capable of supporting more than 3  times the total load of camera and bracket   The maximum load capacity of the mount is 2.5KG  Installation step:  ① Choose the appropriate wall to mount the bracket ② Complete the fixation of bracket and install the camera   to the universal joint and complete the wiring   ...

Warning! Product withdrawn from production!

Replacement product: DS-1299ZJ

Replacement product code: 302701248

Warranty: 36 mon.

Datasheet

DS-3E0108D-E 10/100 Mbps Ethernet Switch  * DS-3E0108D-E: 8 x 10/100 Mbps adaptive Ethernet ports  * Support ADI/ADIX  * Store-and-forward switching  * Support MAC address auto-learning and aging  * Simple and mini exquisite body  * Support desktop and wall-mounting  * Plug & play, and easy to use  Feature and Function    DS-3E0108D-E provides 8 x 10/100 Mbps Ethernet ports  which support line speed forwarding. With simple and mini  exquisite body, the switch is plug and play and easy to use,  suitable for home, school, dormitory, office, small monitoring  and other simple network environments.                      Model DS-3E0108D-E  Network parameters  Port number 8  Port type 10/100 Mbps RJ45 ports  Standard IEEE 802.3, IEEE 802.3u, IEEE 802.3x  Forwarding mode Store and forward  MAC address table 1 K  Switching capacity 1.6 Gbps  Packet forwarding rate 1.1904 Mpps  General  Shell ABS  Weight 0.041 kg  Dimensions (L x H x D) 124 x 59 x 23.2 mm  Operating temperature 0°C~40°C  Storage temperature -40°C~70°C  Operating humidity 10%~90% RH non-condensing  Storage humidity 5%~90% RH non-condensing  Power supply ...

Warranty: 36 mon.

Datasheet

DS-2FA1225-D4  Switching Mode Power Supply    Feature   12 VDC/1 A per channel   Over current/short circuit/over voltage protection   Complies with certification standards of information technology products; good EMC performance   Compact size; applicable to cameras  Dimension    Available Model  DS -2FA1225-D4  Parameter  Model    Parameters  DS -2FA1225 -D4  Switching Mode Power Supply  Appearance Gray  Input 185 to 240 VAC, 50 Hz to 60 Hz  Output 12 VDC /1 A per channel  Cable Length  Compensation  Normal: 12 VDC  Long: 13.5 VDC  Ex-Long: 15 VDC  Ripple & Noise 0.15 Vp -p (15 0 mV)  AC Input Connector C8  DC Output Connector DC Plug: grid terminal  LED Indicator Green  Operating Conditions 0°C to 40°C (32°F to 104°F), Humidity: 10% to 9 5% (non-condensing)  Storage Conditions -40°C to 80°C (-40°F to 176°F), Humidity: 5% to 95% (non-condensing)  Dimension 130 mm x 94 mm x 34 mm (5.11" x 3.70" x 1.34")...

Warning! Product withdrawn from production!

Warranty: 36 mon.

Datasheet

DS-1681ZJ  Adapter for outdoor- indoor PTZ camera threaded connector  made of aluminum alloy, Hikvision brand.  - Material: Aluminum Alloy  - Weight: 5 kg.  Product Features: - Suitable for lifting  indoor PTZ camera.  - It can bear the maximum weight: 10 kg....

Warranty: 36 mon.

Datasheet

DS-1279ZJ (Black)  Extendable Pole for Pendant Mount        Features:   Aluminum alloy material with surface spray  treatment   Match up with pendant mount (DS-1271ZJ)  Dimension:            Order Model:  DS-1279ZJ (Black)  Parameter:  Model  Parameters  DS-1279ZJ (Black)  Extendable Pole for Pendant Mount  Appearance Hikvision Black  Material  Aluminum Alloy  Dimension Φ 38 mm x 250 mm  (Φ 1.50" x 9.84")  Weight Approx. 370 g (0.82 lb.)        Section A-A    C1.5 mm x 1.5 mm  (0.06" x 0.06")    A    A    20 mm (0.79")    G1    G1      4 mm (0.16")    24 mm (0.94") 250 mm (9.84")    Φ 26 mm (1.02")    Φ 38 mm (1.50")...

Warning! Product withdrawn from production!

Warranty: 36 mon.

Datasheet

DS-1291ZJ-BL  Desktop/Pendant Mount for Covert Camera    Features:   Adopt universal regulating mechanism, easy to  adjust   Support desktop mounting and pendant  mounting  Dimension:          Order Model:  DS-1291ZJ-BL  Parameter:  Model    Parameters  DS-1291ZJ-BL  Desktop/Pendant Mount for  Covert Camera  Appearance Black  Material Plastic  Dimension 87x73x73mm  Weight 70.5g        Note: The actual dome camera may vary from the picture above.  1/4-20UNC  44  72.3  72.3  88.3...

Warranty: 36 mon.

Datasheet

DS-1279ZJ  Extendable Pole for Pendant Mount      Features:   Aluminum alloy material with surface spray treatment   Match up with pendant mount(DS-1271ZJ)  Dimension:          Order Model:  DS-1279ZJ  Parameter:  Model    Parameters  DS-1279ZJ  Extendable Pole for Pendant Mount  Appearance Hikvision White  Material Composite Fibre  Dimension Φ38x250mm  Weight    Note: The actual dome camera may vary from the picture above.  Section A-A  C1.5*1.5  A  A  20  G1  G1  4  24  250  □26  □38...

Warranty: 36 mon.

Datasheet

L2 Series Video Surveillance Micro SD (TF) Card    Introduction  Hikvision L2 series Micro SD (TF) card is specially designed for video  surveillance industry. It provides Class 10 R/W speed, adopts TLC  NAND with high compatibility and low price, and is mainly applicable  to low recording intensity scenes or simple operating scenes like lite  storage, standby storage, etc.  Available Models  HS-TF-L2I/16G,  HS-TF-L2I/32G,  HS-TF-L2I/64G,  HS-TF-L2I/128G  Features and Functions   High Cost Performance   Lower price compared to the cards with the same TLC NAND.   Fully satisfies requirements of lite storage.   High Compatibility   Optimized by Hikvision storage system, it is compatible with more products than traditional SD (TF)  cards.   Better performance when used with Hikvision cameras.   Ultra-Strong Adaptability   Waterproof, shock proof, X-ray proof, and wide temperature range.                  Specifications    Note: Performance test is performed in a specific testing environment. Any change of computer system, operation  system, hardware, software, or functions will influence the test result.    Model HS-TF-L2I  Total c...

Warning! Product withdrawn from production!

Warranty: 36 mon.

Datasheet

DS -2FA1201-DL (EUR)  12 VDC Power Adapter    Feature   12 VDC/1 A desktop power adapter   Over current/short circuit/over voltage protection   Complies with certification standards of information technology products; good EMC performance   Compact size; applicable to cameras   Good ingress protection performance helps extend service life of the camera  Dimension    Available Model  DS -2FA1201-DL (EUR)  Parameter  Model    Parameters  DS -2FA1201-DL (EUR)  12 VDC Power Adapter  Appearance Black  Mounting Style Desktop  Input 170 to 240 VAC, 50 Hz  Output 12 VDC /1 A  Ripple & Noise 0.20 Vp -p (200 mV)  Output Power 12 W Max.  AC Input Connector VDE PLUG  DC Output Connector DC Plug: Straight Φ 5.5 x 2.1 x 10 mm , DC Cable: 24AWG 2468 0.8M BLACK  Input Cord Length 350 mm (13.78")  Output Cord Length 800 mm (31.50")  Operating Conditions -10°C to 40°C (14°F to 104°F), Humidity: 10% to 90% (non-condensing)  Dimension 79 mm x 38 mm x 26 mm (3.11" x 1.50" x 1.02")  Weight Approx. 90 g (0.20 lb.)...

Warranty: 36 mon.

Datasheet

DS-3E0105D-E 10/100 Mbps Ethernet Switch  * DS-3E0105D-E: 5 x 10/100 Mbps adaptive Ethernet ports  * Support ADI/ADIX  * Store-and-forward switching  * Support MAC address auto-learning and aging  * Simple and mini exquisite body  * Support desktop and wall-mounting  * Plug & play, and easy to use  Feature and Function    DS-3E0105D-E provides 5 x 10/100 Mbps Ethernet ports  which support line speed forwarding. With simple and mini  exquisite body, the switch is plug and play and easy to use,  suitable for home, school, dormitory, office, small monitoring  and other simple network environments.                      Model DS-3E0105D-E  Network parameters  Port number 5  Port type 10/100 Mbps RJ45 ports  Standard IEEE 802.3, IEEE 802.3u, IEEE 802.3x  Forwarding mode Store and forward  MAC address table 1 K  Switching capacity 1 Gbps  Packet forwarding rate 0.744 Mpps  General  Shell ABS  Weight 0.025 kg  Dimensions (L x H x D) 82 x 52 x 22.4 mm  Operating temperature 0°C~40°C  Storage temperature -40°C~70°C  Operating humidity 10%~90% RH non-condensing  Storage humidity 5%~90% RH non-condensing  Power supply 5 V D...

Warranty: 36 mon.

Datasheet

L2 Series Video Surveillance Micro SD (TF) Card    Introduction  Hikvision L2 series Micro SD (TF) card is specially designed for video  surveillance industry. It provides Class 10 R/W speed, adopts TLC  NAND with high compatibility and low price, and is mainly applicable  to low recording intensity scenes or simple operating scenes like lite  storage, standby storage, etc.  Available Models  HS-TF-L2I/16G,  HS-TF-L2I/32G,  HS-TF-L2I/64G,  HS-TF-L2I/128G  Features and Functions   High Cost Performance   Lower price compared to the cards with the same TLC NAND.   Fully satisfies requirements of lite storage.   High Compatibility   Optimized by Hikvision storage system, it is compatible with more products than traditional SD (TF)  cards.   Better performance when used with Hikvision cameras.   Ultra-Strong Adaptability   Waterproof, shock proof, X-ray proof, and wide temperature range.                  Specifications    Note: Performance test is performed in a specific testing environment. Any change of computer system, operation  system, hardware, software, or functions will influence the test result.    Model HS-TF-L2I  Total c...

Warning! Product withdrawn from production!

Warranty: 36 mon.

Datasheet

DS-1259ZJ  Inclined ceiling mount for DS-2CD21XX dome camera  Features:   Good toughness and strength   Beautiful design with wire outlet hole   Coordination with small and nice appearance   Angle of elevation is increased by 15°  Dimension:      Order model:  DS-1259ZJ  Parameters:  Model  Parameters  DS-1259ZJ  Suitable for DS-2CD21XX series dome cameras  Color Hik white  Feature Suitable for DS-2CD21XX series dome cameras  Angle of elevation is increased by 15°  Material ABS+PC  Dimension Φ111x39.2mm(Φ4.37’’x1.54’’)  Weight 200g(0.44lbs)  Notice:   This bracket is only for DS-2CD21XX series dome camera   Pay attention to the application range when select bracket   Pay attention to the color matching when select bracket   The bracket should be installed on flat wall   The wall must be capable of supporting more than 3 times the total load of  the camera and the mount.   The maximum load capacity of the mount is 2.0KG  Installation steps:  ① Select suitable wall to install the bracket ② Loosen the tightening screw and take down ③ Install the dome core to the gang box, <...

Warranty: 36 mon.

Datasheet
