HIKVISION

DS-1322HZ-C  Outdoor Housing      Features:   All-weather integrated design, convenient installation  and maintenance.   Fully sealed design, high temperature resistance, Anti-  strong wind; storm and dust.   Configure different types of camera lens according to the  respective requirements.  Notice:   Read the instructions carefully and observe all warnings  before installing this equipment.   Turn off the power before wiping this equipment, do not  use liquid or spray cleaning agent.   Do not install on unstable bracket.   Protect the power line, especially the flexible line of the  plug and camera.  Order Model:  DS-1322HZ-C  Dimension:      Parameter:  Model  Parameters  DS-1322HZ-C  Outdoor Housing  Produce features Contain fan, sun shading cover  Working temperature -20℃~+60 ℃  Window area(mm) 77x58  Automatic  temperature control  range  Without heating  Fan on: 45°±5°  Fan off: 30°±5°  Power AC24V  Power consumption 10W  Protection level IP66  Material  Main: aluminum alloy  Window: glass  Dimension(mm) 143x114.5x500  Matching power supply AC24V 1.5A Power pack        ...

Warranty: 36 mon.

Datasheet

DS-1322HZ-H  Outdoor Housing with heater  罩    Features:   All-weather integrated design, convenient installation  and maintenance.   Fully sealed design, high temperature resistance, Anti  strong wind; storm and dust.   Configure different types of camera lens according to the  respective requirements.  Notice:   Read the instructions carefully and observe all warnings  before installing this equipment.   Turn off the power before wiping this equipment, do not  use liquid or spray cleaning agent.   Do not install on unstable bracket.   Protect the power line, especially the flexible line of the  plug and camera.  Order Model:  DS-1322HZ-H  Dimension:      Parameter:  Model    Parameters  DS-1322HZ-H  Outdoor housing  Produce features Contain heater, fan, sun shading cover  Working temperature -40℃~+60 ℃  Window area(mm) 77x58  Automatic  temperature control  range  Heater on: 5°±5°; Heater off: 15°±5°(Fan  operating)  Fan on: 45°±5°; Fan off: 35°±5°  Power AC 24V  Power consumption 55W  Protection level IP66  Material  Main: aluminum alloy  Window: glass  Dimension(mm) 143x114.5x500  Mat...

Warranty: 36 mon.

Datasheet

DS-1330HZ   Indoor Housing    Key Features：   New side cover design, easy for installation   Composite fiber material, low weight   IP54, Good dustproof performance   Silk printing design in lens cover  Order Models：  DS-1330HZ  Dimensions：    Brackets：      Specification：  Model  Parameter  DS-1330HZ  Indoor Housing  Protection Level IP54  Material Composite fiber  Dimension(mm) 290.5x142.9x92.5mm  Weight 640g                                    290.5  104.551   70  46.5  142.9  92.5  1  4UNC-20 D7mm    DS-1203ZJ Pendant Mounting Bracket  DS-1214ZJ Pole Mounting Bracket    DS-1293ZJ Wall Mounting Bracket    DS-1269ZJ Pendant Mounting Bracket...

Warranty: 36 mon.

Datasheet

DS -1331HZ - B  Outdoor Housing      Feature   New side -cover design for convenient installation and maintenance   Stainless steel dual -hasp design, protection level up to IP66   Polycarbonate glass with tempered glass screen protector for lens protection   Built -in fan for keeping the camera working stably   Polycarbonate window for IK10 protection  Dimension and Wiring 130 mm (5.12")  51 mm (2.01")  2-1/4-UNC  Depth: 7  mm (0.28")  4-M6  Depth: 7 mm  (0.28")  50  mm  (1.97  ")  169  .2  mm  (6.66  ")  465.4 mm (18.32")  435.5 mm (17.15")  63.5 mm  (2.50")  160  mm  (6.3")  35  .5  mm  (1.40  ")  110  mm  (4.33  ")  49  .5  mm  (1.95  ")  43  .3  mm  (1.70  ")      RS485  Output  Yellow R484 -  Orange R485 +  DC12V  Output  Black DC12V -  Red DC12V +  Power Input            Available Model  DS -1331HZ -B  Parameter  Model  Parameters  DS -1331HZ -B  Outdoor Housing  Product Feature Built -in fan for use in high temperature environments  Working Temperature -20° C to 60° C ( -4° F to...

Warranty: 36 mon.

Datasheet

DS-1331HZ-C  Outdoor Housing        Features:   Adopt side-cover design for convenient installation and  maintenance.   Adopt stainless steel dual-hasp design, water-proof up to IP 67   Partial glass silk print to protect imaging area   Built-in automatic temperature control system to ensure  stable running.  Notice:   Read the instructions carefully and observe all warnings  before installing this equipment.   Turn off the power before wiping this equipment, do not  use liquid or spray cleaning agent.   Do not install on unstable bracket.   Protect the power line, especially the flexible line of the  plug and camera.  Order Model:  DS-1331HZ-C  Dimension:                Installation:    DS-1293ZJ Wall Mount      DS-1214ZJ Horizontal Pole Mount        DS-1269ZJ Pendent Mount    Parameter:  Model  Parameters  DS-1331HZ-C  Outdoor Housing  Produce features  Contain fan, suitable for high temperature  environment  Working temperature  -20℃ ~ +60℃, Humidity 95% or less  (non-condensing)  Automatic  temper...

Warranty: 36 mon.

Datasheet

DS-1331HZ-CE  Outdoor Housing        Features:   Adopt side-cover design for convenient installation and  maintenance.   Adopt stainless steel dual-hasp design, water-proof up to IP 67   Partial glass silk print to protect imaging area   Built-in automatic temperature control system to ensure  stable running.   POE(802.3at) module for camera and fan  Notice:   Read the instructions carefully and observe all warnings  before installing this equipment.   Turn off the power before wiping this equipment, do not  use liquid or spray cleaning agent.   Do not install on unstable bracket.   Protect the power line, especially the flexible line of the  plug and camera.  Order Model:  DS-1331HZ-CE  Dimension:              Installation:    DS-1293ZJ Wall Mount      DS-1214ZJ Horizontal Pole Mount      DS-1269ZJ Pendent Mount    Parameter:  Model  Parameters  DS-1331HZ-CE  Outdoor Housing  Produce features  Contain fan, suitable for high temperature  environment  Working temperature  -20℃ ~ +60℃, Humidity 95% or less  (non-c...

Warning! Product withdrawn from production!

Warranty: 36 mon.

Datasheet

DS-1331HZ-C  Outdoor Housing        Features:   Adopt side-cover design for convenient installation and  maintenance.   Adopt stainless steel dual-hasp design, water-proof up to IP 67   Partial glass silk print to protect imaging area   Built-in automatic temperature control system to ensure  stable running.  Notice:   Read the instructions carefully and observe all warnings  before installing this equipment.   Turn off the power before wiping this equipment, do not  use liquid or spray cleaning agent.   Do not install on unstable bracket.   Protect the power line, especially the flexible line of the  plug and camera.  Order Model:  DS-1331HZ-C  Dimension:                Installation:    DS-1293ZJ Wall Mount      DS-1214ZJ Horizontal Pole Mount        DS-1269ZJ Pendent Mount    Parameter:  Model  Parameters  DS-1331HZ-C  Outdoor Housing  Produce features  Contain fan, suitable for high temperature  environment  Working temperature  -20℃ ~ +60℃, Humidity 95% or less  (non-condensing)  Automatic  temper...

Warning! Product withdrawn from production!

Warranty: 36 mon.

Datasheet

DS-1331HZ-HI  Outdoor Housing    Features:   Adopt side-cover design for convenient installation and  maintenance.   Adopt stainless steel dual-hasp design, water-proof up to IP 67   Adopt hard coated Polycarbonate to protect imaging area   Built-in automatic temperature control system to ensure  stable running.   Impact protection is up to IK10  Notice:   Read the instructions carefully and observe all warnings  before installing this equipment.   Turn off the power before wiping this equipment, do not  use liquid or spray cleaning agent.   Do not install on unstable bracket.   Protect the power line, especially the flexible line of the  plug and camera.  Order Model:  DS-1331HZ-HI  Dimension:                Installation:    DS-1293ZJ Wall Mount      DS-1214ZJ Horizontal Pole Mount        DS-1269ZJ Pendent Mount  Parameter:  Model    Parameters  DS-1331HZ-HI  Outdoor housing  Produce features Contain heater, fan  Working temperature  -40℃~+60 ℃, Humidity 95% or less  (non-condensing)  Automatic  t...

Warning! Product withdrawn from production!

Warranty: 36 mon.

Datasheet

DS-1331HZ-R  Heat-Resistant Outdoor Housing      Feature   Side-cover design for convenient installation and maintenance   Stainless steel dual-hasp design, up to IP 66   Built-in refrigeration module with 20,000 hours life span   Applicable to high temperature places, e.g. steel plant, and thermal power plant  Dimension and Wiring  521.3 mm (20.5")  489.9 mm (19.3")  141  .4  mm  (5  .6")  136  .8  mm  (5  .4")  108  .9  mm  (4  .3  ")  169.4 mm (6.7")  99  .8  mm  (3  .9  ")  49  .5  mm  (1  .9  ")  204.9 mm (8.1")  51 mm  (2.0")  110 to 240 V AC      Accessory        DS-1293ZJ Wall Mounting  Bracket  DS-1214ZJ Horizontal Pole  Mounting Bracket  DS-1269ZJ Pendent Mounting  Bracket  DS-1233ZJ Column  Mounting Bracket  Available Model  DS-1331HZ-R  Parameter  Model  Parameters  DS-1331HZ-R  Heat-Resistant Outdoor Housing  Working Temperature -30° C to 85° C (-22° F to 185° F)  Temperature Control Refrigeration model enabled, when housing’s temperature is over 45° C (113° F)  Power 110 to 240 V AC  Power Consumption 70 W <...

Warranty: 36 mon.

Datasheet

DS-1331HZ-T  Outdoor Housing    Key Features：   Adopt side-cover design for convenient installation and maintenance   Adopt stainless steel dual-hasp design, water-proof up to IP  67   Partial glass silk print to protect imaging area   Built-in automatic temperature control system to ensure stable running   Hemispheric refractor, suitable for wide-angle lens  Order Model：  DS-1331HZ-T  Dimensions：  454.2  1  6  9  .  2  51  1  1  4  .  6  4  9  .  5  2-1/4UNC-20深8  Unit:mm      Accessary：      Specification：  Model  Parameter  DS-1331HZ-T  Outdoor Housing  Produce Feature  Contain fan, heater, suitable for high & low temperature  environment  Working Temperature -40℃~＋60℃  Automatic temperature  control range  -40℃~＋60℃  Heater on: 5℃±5℃, off: 15℃±5℃（fan on）  Fan on: 45℃±5℃, off: 35℃±5℃  Power AC24/4A  Power Consumption Fan: 4W, Heater: 60W  Protection Level IP67  Material Main: aluminum alloy; Window: Polycarbonate  Dimension(mm) 454.2x169.2x114.6mm  Weight 1.9Kg  Wiring：            DS-1293ZJ Wall Mount  DS-1269ZJ Pendent Mount  DS-121...

Warning! Product withdrawn from production!

Warranty: 36 mon.

Datasheet

DS-1340HZ  Indoor and Outdoor Housing    Key Features：   Self-contained three-axis adjustment bracket, support wall  mounting, pole mounting and pendent mounting.   Self-contained Ethernet port, power and data integration cable   Built-in automatic temperature control system to ensure stable  running.   Up to IP66 protection level, suitable for indoor and outdoor  environment   With junction Box, convenient for wiring.   Impact Protection is up to IK10  Order Model：  DS-1340HZ  Dimension：  537.1  265.2  153.9  100  140  2-?10  Unit:mm      Installation：   Wall Mount, Pendent Mount, Pole Mount    Specification：  Model  Parameter  DD-1340HZ  Indoor and Outdoor Housing  Power Supply 12V/2A  Protection Level IP66  Power Consumption Max.5W  Impact Protection IK10  Material Aluminum alloy  Dimension（mm） 537.1ⅹ153.9ⅹ255.2mm  Weight 5300g    Wiring：                          Internal  wiring  External  Wiring  风扇  黑 DC12V-红 DC12V+...

Warning! Product withdrawn from production!

Warranty: 36 mon.

Datasheet

DS-1471ZJ-135  Pendant Mount    Feature   Aluminum alloy with surface spray treatment   The cable hole design facilitates the cable routing   The cap design facilitates the installation  Dimension  5  6  5    m  m    (  2  2.  2  4"    )  83.5 mm (3.29" )  46 mm (1.81" )  8  3.  5    m  m    (  3  .  2  9"    )    Ø    1  3  6    m  m    (  5  .  3  5"    )  121.2 mm (4.77" )  1  2  1  .  2    m  m    (  4  .  7  7"    )  Ø 150 mm  (5.91" )  4-Ø 8.5 mm  (0.33" )  9-M4 Depth:  8 mm (0.31")      Available Model  DS-1471ZJ-135  Parameter  Model    Parameters  DS-1471ZJ-135  Pendant Mount  Appearance Hikvision White  Material Aluminum Alloy  Dimension Ø 136 mm x 565 mm (5.35" x 22.24")  Weight 1350 g (2.98 lb.)  Note   The mount should be installed on the flat ceiling.   The waterproof rubber is necessary for the outdoor application.   The pole must be capable of supporting at least 3 times as much as the total weight of the camera, and the mount.   The...

Warning! Product withdrawn from production!

Warranty: 36 mon.

Datasheet

DS-1471ZJ-155  Pendant Mount for Dome Camera    Feature   Aluminum alloy with surface spray treatment   Waterproof design  Dimension  5  6  5    m  m    (  2  2.  2  4"  )  Ø 150 mm (5.91")  121.2 mm (4.77")  1  2  1  .  2    m  m    (  4  .  7  7"  )  4-Ø 8.5 mm (0.33")  Ø     1  5  5    m  m    (  6  .  1  "  )  83.5 mm (3.29")  46 mm  (1.81")  8  3.  5    m  m    (  3  .  2  9"  )  6-M4 Depth 8 mm  (0.31")      Available Model  DS-1471ZJ-155  Parameter  Model    Parameters  DS-1471ZJ-155  Pendant Mount for Dome Camera  Appearance Hikvision White  Material Aluminum Alloy  Dimension Ø 155 mm x 565 mm (6.1" x 22.24")  Weight 650 g (1.4 lb.)  Note   The mount should be installed on the flat surface.   Waterproof rubber is necessary for the outdoor application.   The wall must be capable of supporting at least 3 times as much as the total weight of the camera and the mount.   The mount’s maximum load capacity is 3 Kg (6.6 lb.).      0100001070711...

Warranty: 36 mon.

Datasheet

DS -1471ZJ -155 -Y  Pendant Mount    Feature   Adopts waterproof design  Dimension 565  mm  (22  .24  ")  Φ 150 mm (5.91")  121.2 mm (4.77")  121  .2   mm  (4  .77  ")  4-Φ 8.5 mm (0.33")  83.5 mm (3.29")  46 mm  (1.81")  83  .5   mm  (3  .29  ")  6-M4 depth 8 mm  (0.31")      Available Model  DS -1471ZJ-155-Y  Parameter  Model    Parameters    DS -1471ZJ-155-Y  Pendant Mount  Appearance Hikvision White  Material ADC12  Dimension Φ 155 mm x 565 mm (Φ 6.1 " x 22.24 ")  Weight Approx. 650 g ( 1.4 lb.)  No te   The mount should be installed on a flat surface.   The waterproof rubber is necessary for the outdoor application.   The wall should be capable of supporting at least 3 times as much as the total weight of the camera, and the mount.   The maximum load capacity of the mount is 3 kg (6.6 lb.)....

Warning! Product withdrawn from production!

Warranty: 36 mon.

Datasheet
