Description

Warranty: 36 mon.

Datasheet

Text contents of PDF datasheet:

Lite series | DHI-NVR4104/4108/4116-P

System Overview
Dahua's NVR4000 is one of the NVRs which have the most reasonable
price and best quality for IP video surveillance applications. This Lite
NVR provides up to 5MP resolution. Additionally, the NVR features a
mouse shortcut operation menu, remote management and control,
centre storage, edge storage, and back up storage.
Designed as a low-cost, easy installation, this NVR is ideal for a
wide range of applications such as public safety, water conservancy,
transportation, city centers, education, and financial institutions.
The NVR is compatible with numerous third-party devices making it
the perfect solution for surveillance systems with or without a video
management system (VMS). Its open architecture supports multi-user
access and is compatible with ONVIF 2.4, enabling interoperability when
combined with IP cameras.

Functions
Smart H.264+
Delivering high quality video without straining the network, Smart
H.264+ is the optimized implementation of H.264. The Smart H.264+
encoding platform includes a scene adaptive encoding strategy, dynamic
GOP, dynamic ROI, flexible multi-frame reference structure and intelligent
noise reduction, providing a savings of up to 70% of bandwidth and
storage when compared with standard H.264.
Smart Add
With the Smart Add function, the installation of IP system is as easy as an
analog system, no matter the NVR with or withou a PoE switch embeded.
It should be noted that the NVR has to be in the same router as cameras.
ANR (Automatic Network Replenishment Technology)
Video record in SD card in IP cameras when the network breaks down,
and after the network recovered, the video will be transferred to NVR
and then recorded in it.
P2P
You can monitor at anytime and anywhere with P2P. With this function,
you can manage your devices more convenient.
www.dahuasecurity.com

· H.264+/H.264 codec decoding
· Max 80Mbps Incoming Bandwidth
· Up to 5MP Resolution for Preview and Playback
· HDMI/VGA simultaneous video output
· Support IPC UPnP, 4PoE ports
· Support ANR technology to enhance the storage reliability
when the network break down
DHI-NVR4104/4108/4116-P
4/8/16 Channel 4PoE Smart 1U Lite Network Video Recorder

Series
Lite

H.264
+

5Mp

Plug&Play

Dual
Core
Processor

www.dahuasecurity.com
Lite Series | DHI-NVR4104/4108/4116-P

Technical Speciﬁcation
System
Main ProcessorDual-core embedded processor
Operating System
Embedded LINUX
Display
Interface1 HDMI, 1 VGA
Resolution1920 x 1080 , 1280 x 1024, 1280 x 720 , 1024 x 768
Multi-screen Display
4CH: 1/4
8CH: 1/4/8/9
16CH: 1/4/8/9/16
OSD
Camera title, Time, Video loss, Camera lock,
Motion detection, Recording
Video Detection and Alarm
Trigger Events
Recording, PTZ, Tour, Video Push, Email, FTP,
Snapshot, Buzzer and Screen Tips
Video Detection
Motion Detection, MD Zones: 396 (22 x 18),
Video Loss and Camera Blank
Alarm inputN/A
Relay OutputN/A
Playback and Backup
Playback
4CH: 1/4
8CH: 1/4/8
16CH: 1/4/8/16
Search Mode
Time /Date, MD and Exact Search
(accurate to second), Smart search
Playback Function
Play, Pause, Stop, Rewind, Fast play, Slow Play,
Next File, Previous File, Next Camera,
Previous Camera, Full Screen, Repeat, Shuffle,
Backup Selection, Digital Zoom
Backup ModeUSB Device/Network
Storage
Internal HDD1 SATA III Port, Up to 6 TB capacity for each HDD
HDD ModeSingle
eSATAN/A
Auxiliary Interface
USB2 USB Ports (2 USB2.0)
RS232N/A
RS485N/A
Third-party Support
Third-party Support
Dahua, Arecont Vision, AXIS, Bosch, Brickcom,
Canon, CP Plus, Dynacolor, Honeywell, Panasonic,
Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek,
and more

Audio and Video
IP Camera Input4/8/16 Channel
Two-way Talk1 Channel Input, 1 Channel Output, RCA
Recording
CompressionH.264+/H.264/MJPEG
Resolution5MP/ 4MP/ 3MP/ 1080P/ 1.3MP/ 720P etc.
Record Rate80Mbps
Bit Rate16Kbps ~ 20Mbps Per Channel
Record Mode
Manual, Schedule (Regular, Continuous), MD
(Video detection: Motion Detection, Camera Blank,
Video Loss), Stop
Record Interval
1 ~ 120 min (default: 60 min), Pre-record:
1 ~ 30 sec, Post-record: 10 ~ 300 sec
Network
Interface1 RJ-45 Port (10/100Mbps)
Ethernet Port1 Independent 100Mbps Ethernet Port
PoE4 ports (IEEE802.3at/af)
Network Function
HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP,
NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP,
Alarm Server, IP Search (Support Dahua IP camera,
DVR, NVS, etc.)
Max. User Access128 users
Smart PhoneiPhone, iPad, Android
InteroperabilityONVIF 2.4, CGI Conformant
Electrical
Power SupplyDC48V/1.5A
Power Consumption<10W (Without HDD)
Environmental
Operating Conditions-10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa
Storage Conditions-20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH
Construction
Dimensions
Smart 1U, 204.6mmx204.6mmx45.6mm
(8.1" x 8.1" x 1.8")
Net Weight0.5kg (1.1 lb) (without HDD)
Gross Weight1.5kg(3.31 lb)(without HDD)
Certifications
CEEN55022, EN55024, EN50130-4, EN60950-1
FCCPart 15 Subpart B, ANSI C63.4-2014
ULUL60950-1+CAN/CSA C22.2 No.60950-1

Lite Series | DHI-NVR4104/4108/4116-P
Rev 001.001© 2016 Dahua . All rights reserved. Design and specifications are subject to change without notice

Ordering Information
TypePart NumberDescription
4 Channel NVR DHI-NVR4104-P
4 Channel 4PoE Smart 1U Lite
Network Video Recorder
8 Channel NVR DHI-NVR4108-P
8 Channel 4PoE Smart 1U Lite
Network Video Recorder
16 Channel NVR DHI-NVR4116-P
16 Channel 4PoE Smart 1U Lite
Network Video Recorder
Accessories N/AN/A
www.dahuasecurity.com

Dimensions (mm)
