IVSS7024DR-8M

DeepSense series | DHI-IVSS7024DR-8T     System Overview  Dahua IVSS goes beyond the ordinary NVR products. It is an Intelligent  Video Surveillance Server combines video management functions with  traditional video storage operations in one device. Besides the basic  functions as network video recorder, IVSS is integrated with features such  as face detection, face recognition for different business and industrial  applications.  With build-in deep learning module, IVSS series products adopt video  image structuring technology based on deep learning algorithms,  achieving high-precision human face analysis, comparison, retrieval,  storage, and management. By applying deep learning artificial  intelligence, IVSS allow users to focus on what matters most, improve  event response time and help make video actionable.  An all new UI design supports device operation and maintenance  management, improving the value and experience of surveillance view,  and servicing the era of security big data.   Functions  Real Time Face Recognition  Up to 32 channel real time face recognition by IVSS. Facial attribut...

Warranty: 36 mon.

Datasheet

Text contents of PDF datasheet:

DeepSense series | DHI-IVSS7024DR-8T

System Overview
Dahua IVSS goes beyond the ordinary NVR products. It is an Intelligent
Video Surveillance Server combines video management functions with
traditional video storage operations in one device. Besides the basic
functions as network video recorder, IVSS is integrated with features such
as face detection, face recognition for different business and industrial
applications.
With build-in deep learning module, IVSS series products adopt video
image structuring technology based on deep learning algorithms,
achieving high-precision human face analysis, comparison, retrieval,
storage, and management. By applying deep learning artificial
intelligence, IVSS allow users to focus on what matters most, improve
event response time and help make video actionable.
An all new UI design supports device operation and maintenance
management, improving the value and experience of surveillance view,
and servicing the era of security big data.
Functions
Real Time Face Recognition
Up to 32 channel real time face recognition by IVSS. Facial attributes
analysis features including gender, age, expression, glasses, moustache,
mouth mask. Identify people and also capture, record faces with
structured data. Facial feature filtering while real time display, only show
faces with target features.
Regular/Stranger Mode
IVSS support regular and stranger mode. In stranger mode, when IVSS
detect a stranger face(not in device's face database), it can trigger alarm,
buzzer, snapshot, record, etc. Similarity threshold can be set manually.
This function is developed for important infrastructure sites for which
access control is critical.
Efficient Search
Support uploading face pictures to IVSS and compare them with
recorded faces in IVSS by similarity. Enable operators to quickly and easily
search through multi channels and long duration, efficiently find out
when and where a person of interest appeard.
Face Database Management
Configurable multiple face databases. Powerful face database
management. Face database can be applied to video channels
independently. Name, gender, birthday, nationality, address, ID
information can be added to each face picture.
www.dahuasecurity.com

· Intel quad-core processor
· Max 512Mbps incoming bandwidth
· 256 Channel IP video access
· Up to 32 Channel back end face recognition
· Regular/stranger mode
· Search by image
· Face database management
· Supports RAID 0/1/5/6/10
· SAS3.0 for storage extension
· 3HDMI/1VGA video output
· Redundant power
DHI-IVSS7024DR-8T
4U 24HDD AI Network Video Recorder

DeepSense series products adopt the most advanced AI technologies,
including deep learning algorithms that primarily target people and
vehicles, which provides higher flexibility and accuracy for end-users.
This enables the Dahua DeepSense series to offer various advanced
applications such as Face Recognition, ANPR, Metadata, People
Counting, traffic data statistics, etc.
The complete lineup of Dahua DeepSense includes network (PTZ)
cameras, network video recorders, servers, and platform management
products. Beyond seeing the world, the power of AI allows devices to
perceive the environment and understand the world in a better way.


www.dahuasecurity.com
DeepSense series | DHI-IVSS7024DR-8T

Technical Specification
System
Main Processor Intel Quad-core Processor
Memory16GB, up to 64GB
Operating System
Embedded LINUX
Artificial Intelligence
Face RecognitionUp to 32 channel face recognition
Metadata
Sturctured data of gender, age, expression, glasses,
moustache, mouth mask information.
Stranger Mode
Detect strangers' faces(not in device's face database).
Similarity threshold can be set manually.
Trigger EventsBuzzer, snapshot, recording, etc.
Search by Image
Up to 10 target face images search at same time. Support
similarity threshold set for each target face image.
Database Management
Up to 20 face databases with 100,000 face images in
total. Name, gender, birthday, nationality, address, ID
information can be added to each face picture.
Database Application
Each database can be applied to video channels
independently.
Audio and Video
IP Camera Input256 Channel
Two-way Talk1 x 3.5mm audio input, 1 x 3.5mm audio output
Display
Interface3 HDMI, 1VGA
Resolution
HDMI1/2/3 : 3840 x 2160 , 1920 x 1080 , 1280 x 1024,
1280 x 720
VGA : 1920 x 1080 , 1280 x 1024,
1280 x 720
Decoding Capability24-ch@1080P(30fps)
Multi-screen DisplayUp to 36 split for each screen
OSDCamera title, Time, Motion detection, Recording
Recording
Bandwidth450Mbps
CompressionH.265/H.264/MJPEG/MPEG4
Resolution12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, etc.
Record ModeSchedule (Continuous, Event)
Video Detection and Alarm
Trigger EventsRecording, Snapshot, Buzzer, etc.
Video DetectionMotion Detection, MD Zones: 396 (22 x 18); Tampering
Alarm input16 Channel
Relay Output8 Channel
Playback and Backup
Sync PlaybackUp to 16ch sync playback, 128Mbps playback bandwidth
Search Mode
Time /Date, Video Detection, Face and Exact Search
(accurate to second)
Backup ModeUSB Device/Network


Third-party Support
Third-party SupportAXIS, Panasonic, Sony, etc.
Network
Interface4 RJ-45 Ports (10/100/1000Mbps)
Optional Interface4 Giga Optical Fiber Interface
Network Port Mode
Independent Ethernet Ports, Load Balance, Fault-
Tolerance, Link Aggregation
Network Function
HTTP, HTTPS, TCP/IP, UDP, RTSP, IPv4, NTP, DHCP,
DNS, IP Filter, IP Search (Support Dahua IP camera,
DVR, etc.), P2P
InteroperabilityONVIF 2.4, SDK
Storage
Internal HDD
24 SAS/SATA HDDs, Up to 10 TB capacity for each
HDD, Independent HDD bracket, hot-swap
HDD Mode
Single, Raid 0/1/5/6/10(Enterprise-level HDDs are
recommended), Support Global HDD Hot-spare
eSATA
1 eSATA Port (Please contact technical engineer to
confirm the compatible device)
SAS2 SAS3.0 Ports
Auxiliary Interface
Front Cover
Support Hot-swap, 7-inch HD LCD (1920 x 1080 ,
1280 x 1024)
USB4 USB Ports (2 USB 2.0 , 2 USB 3.0 )
RS2321 Port, for PC Communication
RS4851 Port
Electrical
Power SupplyAC100V ~ 240V, 50 ~ 60 Hz, Hot-swap, Redundant
Power Consumption<130W (Without HDD)
FanDual-ball bearing fans, Hot-swap
Environmental
Operating Conditions0°C ~ +45°C (+32°F ~ +113°F), 86 ~ 106kpa
Storage Conditions-20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH
Construction
Dimensions
4U, 482.6mm x 543.4mm x 175mm (19" x 21.39" x
6.89")
Net Weight20kg (44.09 lb) (without HDD)
InstallationStandard 19-inch Rack-mounted
Certifications
CEEN55032, EN55024, EN50130-4, EN60950-1
FCCPart 15 Subpart B, ANSI C63.4-2014
ULUL 60950-1

DeepSense series | DHI-IVSS7024DR-8T
Rev 001.001© 2018 Dahua . All rights reserved. Design and specifications are subject to change without notice

Ordering Information
TypePart NumberDescription
IVSSDHI-IVSS7024-8T
4U 24HDD Intelligent Video Surveillance
Server with 32 Channel Back End Face
Recognition
IVSSDHI-IVSS7024DR-8T
4U 24HDD Intelligent Video Surveillance
Server with Redundant Power, LCD
screen and 32 Channel Back End Face
Recognition
Relevant
Products
DH-IPC-HF8242F-FD
2MP Starlight Face Detection Box
Network Camera
www.dahuasecurity.com

DH-HF8242F-FD
Relevant Products
Dimensions(mm)
