IPC-HF5442E-E

Availability: 0
Price: €437.51 437.51
excl. 23.00% TAX, excl. shipping costs
quantity szt.

product unavailable

add to wish list
Vendor: DAHUA
Product code: IPC-HF5442E-E

Description

Pro AI Series | DH-IPC-HF5442E-E    www.dahuasecurity.com  DH-IPC-HF5442E-E  4MP Starlight Bullet AI Network Camera    Dahua AI series products adopt the most advanced AI technologies,  including deep learning algorithms that primarily target people and  vehicles, which provides higher flexibility and accuracy for end-users.  This enables the Dahua AI series to offer various advanced applications  such as Face Recognition, ANPR, Metadata, People Counting, traffic data  statistics, etc.The complete lineup of Dahua AI includes network (PTZ)  cameras, network video recorders, servers, and platform management  products. Beyond seeing the world, the power of AI allows devices to  perceive the environment and understand the world in a better way.  System Overview  Pro AI series contains Face Capture, Perimeter Protection and People  Counting functions.Powered by deep-learning Artificial Intelligence  algorithms, significantly improved accuracy. Active Deterrence and  Full Color camera are also in this series. Meanwhile, the series features  starlight and smart IR technology. This series fully protected from dust  and water.  Functions  Face Capture  Face capture is a software application that aut...

Warranty: 36 mon.

Datasheet PDF


Text contents of PDF datasheet:

Pro AI Series | DH-IPC-HF5442E-E

www.dahuasecurity.com
DH-IPC-HF5442E-E
4MP Starlight Bullet AI Network Camera

Dahua AI series products adopt the most advanced AI technologies,
including deep learning algorithms that primarily target people and
vehicles, which provides higher flexibility and accuracy for end-users.
This enables the Dahua AI series to offer various advanced applications
such as Face Recognition, ANPR, Metadata, People Counting, traffic data
statistics, etc.The complete lineup of Dahua AI includes network (PTZ)
cameras, network video recorders, servers, and platform management
products. Beyond seeing the world, the power of AI allows devices to
perceive the environment and understand the world in a better way.
System Overview
Pro AI series contains Face Capture, Perimeter Protection and People
Counting functions.Powered by deep-learning Artificial Intelligence
algorithms, significantly improved accuracy. Active Deterrence and
Full Color camera are also in this series. Meanwhile, the series features
starlight and smart IR technology. This series fully protected from dust
and water.
Functions
Face Capture
Face capture is a software application that automatically captures faces
from within a digital image or a video frame from a video source. Dahua
cameras use advanced deep learning algorithms and are trained by a
large number of face data sources, enabling the camera to locate faces
quickly and accurately from the video source and capture facial images.
Face Attributes
Through the use of deep learning algorithms to analyze facial images,
Dahua cameras can extract six facial attributes from each frame, includ-
ing Age, Gender,Expression(Jolly/Surprise/Normal/Rage/Sad/Disgusted/
Confused/Frightened), Glasses,Mouth Mask, Moustache & Beard. Cus-
tomers can acquire data of interest via face attributes statistics.
Perimeter Protection
Dahua’s Perimeter Protection functions significantly improved accu-
racy. Perimeter Protection reduces false alarms and decreases pixel
count requirements for object detection. Perimeter Protection features
custom tripwires based on object type for automation in limited access
areas such as pedestrian or vehicle-only zones. This combination of
advanced AI analytics and real-time alerts to a desktop or to a mobile
client reduces system requirements and resources resulting in greater
surveillance system efficiency.
People Counting
People Counting function uses advanced image processing technology
to capture depth information from within images. The camera pairs this
information with deep learning algorithms to analyze and detect human
bodies and track target objects in real time. The camera provides statis-
tics for separate individuals’ entrance and exit with up to 95% counting
accuracy.
Metadata
Metadata is feature attribute information extracted from a target object
which can be used for data retrieval. Dahua face detection camera can
extract six facial attributes and output the metadata for analysis.
ePoE technology
The ePoE technology of Dahua, designed internally, adopts advanced
2D-PAM3 coding modulation from physical layer, and realizes full duplex
transmission over 800 meters at the speed of 10Mbps, or 300 meters at
the speed of 100Mbps via Cat 5 or coaxial cable media. Besides, it sup-
ports PoE and PoC power supply technology which has greatly simplified
construction and wiring. Dahua ePoE technology offer a new way to
accomplish long distance transmission between IP camera and network
switch. It allows more flexible surveillance system design, improves reli-
ability and saves construction and wiring cost.
· 1/1.8” 4Megapixel progressive scan CMOS
· H.265&H.264 triple-stream encoding
· 25/30fps@2688x1520
· WDR(120dB), Day/Night(ICR), 3D DNR,AWB,AGC,BLC
· Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
· 2/1 Alarm in/out, 1/1 audio in/out
· Micro SD memory


www.dahuasecurity.com
Pro AI Series | DH-IPC-HF5442E-E

Technical Specification
Camera
Image Sensor1/1.8” 4Megapixel progressive scan CMOS
Effective Pixels
2688(H)x1520(V)
RAM/ROM
1GB/128MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual, 1/3~1/100000s
Minimum Illumination
0.008Lux/F1.5 ( Color,1/3s,30IRE)
0.060Lux/F1.5 ( Color,1/30s,30IRE)
0Lux/F1.5 (IR on)
LED Distance
N/A
LED On/Off Control
N/A
LEDs
N/A
Lens
Lens TypeN/A
Mount TypeC/CS
Focal LengthN/A
Max. ApertureN/A
Angle of ViewN/A
Optical ZoomN/A
Aperture TypeN/A
Close Focus DistanceN/A
Pan/Tilt/Rotation
Pan/Tilt/Rotation RangeN/A
Artificial Intelligence
Face CaptureSupport face image capture
Face Attributes
Support 6 kinds of face attributes extraction: Age,
Gender,Expression(Jolly/Surprise/Normal/Rage/Sad/
Disgusted/Confused/Frightened), Glasses,Mouth Mask,
Moustache & Beard
Perimeter ProtectionTripwire, Intrusion(Human & Vehicle classification)
People CountingLine crossing people counting, Region people counting
General Intelligence
Event Trigger
Motion detection, Video tampering , Scene changing,
Network disconnection , IP address conflict, Illegal
Access,Storage anomaly
General IntelligenceObject Abandoned/Missing
Video
Compression
H.265+/H.265/H.264+/H.264/H.264B/H.264H/
MJPEG(sub stream)
Streaming Capability3 Streams
Resolution
2688x1520/2304x1296/1080P(1920x1080)/1.3M(1
280x960)/720P(1280x720)/D1(704x576/704x480)/
VGA(640x480)/CIF(352x288/352x240)


Frame Rate
Main Stream: 2688x1520(1~25/30fps)
Sub Stream: D1(1~25/30fps)
Third Stream: 1080P(1~11fps)
Bit Rate ControlCBR/VBR
Bit Rate
H.264: 32~ 8192Kbps
H.265: 19~ 8192Kbps
Day/NightAuto(ICR) / Color / B/W
BLC ModeBLC / HLC / WDR(120dB)
White BalanceAuto/Natural/Street Lamp/Outdoor/Manual
Gain ControlAuto/Manual
Noise Reduction3D DNR
Motion DetectionOff / On (4 Zone, Rectangle)
Region of InterestOff / On (4 Zone)
Electronic Image Stabilization
(EIS)
Support
Smart IRN/A
DefogSupport
Digital ZoomN/A
Flip0°/90°/180°/270°
MirrorOff / On
Privacy MaskingOff / On (4 Area, Rectangle)
Audio
CompressionG.711a/ G.711Mu/ AAC/ G.726/G.723
Network
EthernetRJ-45 (10/100Base-T)
Protocol
HTTP; TCP; ARP; RTSP; RTP; UDP; RTCP;SMTP;
FTP; DHCP; DNS; DDNS; PPPoE; IPv4/v6; SNMP;QoS;
UPnP;NTP
Interoperability
ONVIF(Profile S/Profile G),
CGI,Milstone,Genetec,P2P
Streaming MethodUnicast / Multicast
Max. User Access20 Users
Edge Storage
NAS
FTP
Micro SD card 256GB
Web Viewer
IE(versions newer than IE8), Chrome,
Firefox, Safari(versions newer than Safari 12)
Management SoftwareSmart PSS, DSS, P2P
Smart PhoneiOS, Android
Certifications
Certifications
CE-LVD:EN60950-1
CE-EMC:Electromagnetic Compatibility Directive
2014/30/EU
FCC:47 CFR FCC Part 15, Subpart B
UL/CUL:
UL60950-1
CAN/CSA C22.2 No.60950-1-07

Pro AI Series | DH-IPC-HF5442E-E

Ordering Information
TypePart NumberDescription
4MP camera
DH-IPC-HF5442EP-E
4MP Starlight Bullet AI Network Camera,
PAL
DH-IPC-HF5442EN-E
4MP Starlight Bullet AI Network Camera,
NTSC
IPC-HF5442EP-E
4MP Starlight Bullet AI Network Camera,
PAL
IPC-HF5442EN-E
4MP Starlight Bullet AI Network Camera,
NTSC
Accessories
(optional)
PFB110W Ceiling Mount
PFB121W Wall Mount
www.dahuasecurity.com

Interface
Video Interface1 port(BNC,1Vp-p,75Ω )
Audio Interface1/1 channel In/Out,Built-in MIC
RS4851 port
Alarm
2 channel In: 5mA 5VDC
1 channel Out: 1A 30VDC / 0.5A 50VAC
Power Out165mA 12VDC
Electrical
Power SupplyDC12V(±25%), AC24V(±25%), PoE(802.3af)(Class 0)
Power Consumption
DC12V:4.1W 9.2W(IR on)
AC24V: 4.3W 8.7W(IR on)
PoE:4.4W 9.2W(IR on)
Environmental
Operating Conditions-30° C ~ +60° C (-22° F ~ +140° F) / 10%RH~95% RH
Storage Conditions
+5° C ~ +40° C (+41° F ~ +104° F) (daily temperature
difference within 15° C/59° F ) / 10%RH~95% RH
Ingress Protection
N/A
Vandal ResistanceN/A
Construction
CasingMetal
Dimensions135.4mm*74.4mm*65.5mm(5.33”x2.93”x2.58”)
Net Weight0.53Kg (1.17lb)
Gross Weight0.62Kg (1.37lb)
Accessories
Optional:
Dimensions (mm/inch)
Rev 001.001© 2019 Dahua. All rights reserved. Design and specifications are subject to change without notice.

PFB110W
Wall Mount
PFB121W
Wall Mount
LR1002
ePoE Over Coax Converter

W all Mo un tW all/Ceili n g / Plane Moun t
PFB0W PFB2W
