HV3816P-8MPIR
Description
HV3816P-8MPIR Features P - Iris vari -focal eight megapixel IR lens （aspherical ） Specification Lens Parameters Focal Length: 3.8~16mm Aperture Range: F1.5 - C Lens Mount: CS Format: Φ9mm（1/1.8" ) Horizontal Angle of View: 1/1.8" :103.1°~28.0° 1/2" :100.7°~27.3° Min.Working Distance: 0. 1 m Iris Control: P - Iris Weight: 237g Dimension: Φ55*75mm 2002 - 201 5©Hikvision Digital Technology Co., Ltd. All Rights Reserved....
Warranty: 36 mon.
Datasheet
Text contents of PDF datasheet:
HV3816P-8MPIR
Features
P - Iris vari -focal eight megapixel IR lens （aspherical ）
Specification
Lens Parameters
Focal Length: 3.8~16mm
Aperture Range: F1.5 - C
Lens Mount: CS
Format:
Φ9mm（1/1.8" )
Horizontal Angle of View:
1/1.8" :103.1°~28.0°
1/2" :100.7°~27.3°
Min.Working Distance: 0. 1 m
Iris Control: P - Iris
Weight: 237g
Dimension: Φ55*75mm
2002 - 201 5©Hikvision Digital Technology Co., Ltd. All Rights Reserved.
