GV-GIS 5 (100-500)

Availability: 0
Price: €88.14 88.14
excl. 23.00% TAX, excl. shipping costs
quantity szt.

product unavailable

add to wish list
Vendor: GEOVISION
Product code: 00145

Description

INTRODUCTION  The GV ‐ GIS is a GIS (Geographic Information System)  based central management system for GeoVision  devices.  The vehicle tracking and remote location verification  from the GV ‐ GIS is made possible by the GPS  receiver attached to GV ‐Video Server and  GV ‐Compact DVR to constantly obtain the GPS data  (vehicle coordinates and speed) from the satellite,  and through mobile internet connection (e.g. UMTS,  EV ‐DO, EDGE, GPRS, GSM, etc) to transmit the GPS  data to the GV ‐ GIS.  Besides real ‐time vehicle tracking, you can also  monitor ...

Warranty: 36 mon.

Datasheet PDF


Text contents of PDF datasheet:

INTRODUCTION
The GV ‐ GIS is a GIS (Geographic Information System)
based central management system for GeoVision
devices.
The vehicle tracking and remote location verification
from the GV ‐ GIS is made possible by the GPS
receiver attached to GV ‐Video Server and
GV ‐Compact DVR to constantly obtain the GPS data
(vehicle coordinates and speed) from the satellite,
and through mobile internet connection (e.g. UMTS,
EV ‐DO, EDGE, GPRS, GSM, etc) to transmit the GPS
data to the GV ‐ GIS.
Besides real ‐time vehicle tracking, you can also
monitor the location of cameras and the status of
I/O devices from the DVR and NVR, without GPS
functions for city surveillance.

Features
• GIS central management system
• 500 vehicles tracking at one time
• Real‐ time vehicle GPS coordinates
• Real‐ time vehicle video image
• Google Maps, Microsoft Virtual Earth and
user ‐defined maps support
• GPS Tracks playback
• Detour Detection
• Idle Speed Detection
• Over Speed Detection
• E ‐Map Support
• Motion and Input ‐triggered alert for fixed hosts
• Customized landmark (interested points) setting
• Integration with GV ‐I/O Box, GV ‐Video Server,
GV ‐Compact DVR, GV ‐ IP Camera, GV ‐System and
GV ‐NVR
• GIS Web Interface for remote monitoring and
tracking




GV-GIS May 25, 2015
-1-

Minimum System Requirements
32‐ bit
Windows XP / Vista / 7 / 8 / Server 2008
OS
64‐ bit
Windows 7 / 8 / Server 2008 / Server 2012
CPU
Core i3 2120K 3.3 GHz / Core i5 2500K 3.3 GHz / Core i7 2600K 3.4 GHz
See the table below for detail

Memory 2 X 1 GB Dual Channels

Hard Disk 1 GB.

Graphic Card AGP or PCI‐ Express, 800 x 600 (1280 x 1024 recommended), 32 ‐ bit color

Direct X 9.0c

Browser Internet Explorer 7.X

Software .Net Framework 3.5

Hardware External or Internal GV ‐ GIS Dongle

Note: The .Net Framework can be found in the Software DVD.


Software License
Free License N/A

Maximum License 500 mobile hosts

Increment for Each License 1, 3, 5, 10 or 10 plus an increment of 5 up to a total of 500 vehicle connections

Optional Combinations
1. GIS
2. GIS + VSM

Dongle Type Internal or external

Note: It is recommended to use the internal GV ‐ USB Dongle to have the Hardware Watchdog function which restarts the PC when
Windows crashes or freezes.



Total Frame Rate based on CPU Type
The total frame rates (fps) of 16 live views are listed below according to the resolution, codec and CPU type.

CPU
Core i3 2120K
Core i5 2500K Core i7 2600K
Resolution Codec
Total Frame Rate (fps)
H.264
MJPEG 320 x 240
MPEG4
480
H.264 390
640 x 480
MJPEG 480
480
H.264 390
MJPEG 450 720 x 480
MPEG4 480
480
H.264 180 330 450

1280 x 1024
MJPEG 240 450 480

H.264 120 210 270

1920 x 1080
MJPEG 240 330 480

H.264 80 140 200

2048 x 1536
MJPEG 180 240 320

H.264 75 120 165

2048 x 1944
MJPEG 135 180 240

H.264 90 130 160

2560 x 1920
MJPEG 130 160 160



Specifications
GV-GIS May 25, 2015
-2-

GV-GIS May 25, 2015
-3-
Feature Amount Device
Mobile Host
Up to 500 hosts
depending on the Dongle in use)
GV ‐ Video Server
GV ‐Compact DVR
Fixed Host Unlimited
GV ‐DVR/NVR, GV ‐ Video Server, GV ‐Compact DVR, GV ‐ IP Cam, GV ‐Speed
Dome, GV ‐Smart Box, GV ‐ I/O Box 8/16 Ports (Ethernet Module), GV ‐LPR
GV ‐ DSP LPR, 3rd ‐party IP devices
I/O Module 9 units
GV ‐ I/O
GV ‐ I/O Box (4/8/16 Ports)
Live View 16 views Mobile Hosts + Fixed Hosts
Map View 16 views Mobile Hosts
Marker Unlimited
ViewLog 1 Remote ViewLog program required to be installed
Instant Playback 1
Language
Arabic / Bulgarian / Czech / Danish / Dutch / English / Finnish / French / German / Greek / Hebrew / Hungarian /
Indonesian / Italian /Japanese / Lithuanian / Norwegian / Persian / Polish / Portuguese / Romanian / Russian /
Serbian / Simplified Chinese / Slovakian / Slovenian / Spanish / Swedish / Thai / Traditional Chinese / Turkish

Options
Optional Devices
Description
Internal USB Dongle
The USB dongle can provide the Hardware Watchdog function to the GV ‐ GIS by restarting the
computer when Windows crashes. You need to connect the dongle internally on the motherboard.

GV ‐ IO Box (4 Ports V1.0/V1.1)
GV ‐ IO Box 4 Ports V1.0/V1.1 provides 4 inputs and 4 relay outputs, and supports both DC and AC
output voltages. A USB port is also provided for PC connection.

GV ‐ IO Box (4 Ports V1.2)
GV ‐ IO Box 4 Ports V1.2 provides 4 inputs and 4 relay outputs. It supports both DC and AC output
voltages, and provides a USB port for PC connection.

GV ‐ IO Box (8 Ports)
GV ‐ IO Box 8 Ports provides 8 inputs and 8 relay outputs, and supports both DC and AC output
voltages. A USB port is also provided for PC connection.

GV ‐ IO Box (16 Ports)
GV ‐ IO Box 16 Ports provides 16 inputs and 16 relay outputs, and supports both DC and AC output
voltages. A USB port is also provided for PC connection.
