Description

Warranty: 36 mon.

Datasheet

Text contents of PDF datasheet:

INTRODUCTION
The GV ‐Dispatch Server is a computer with Dispatch software that works with GV ‐Center V2 servers and the GV ‐System / GV ‐ VMS. The
GV ‐Dispatch Server connects 25,000 GV ‐System / GV ‐VMS to 50 GV ‐Center V2 Pro servers and distributes the workload between
online and offline GV ‐ Ce nter V2 servers. It utilizes load ‐balancing technique that distributes requests from event ‐triggered GV ‐System
/ GV ‐ VMS evenly across a GV ‐Center V2 network. If one GV ‐Center V2 server starts to get swamped, the GV ‐Dispatch Server forwards
requests to another GV ‐Center V2 server with more capacity. When one GV ‐Center V2 server fails to work, another can take over in
the processing activity.

REASONS OF RECOMMENDATION

Important for large GV ‐Center V2 server farm: It is difficult to predict the number of requests from multiple GV ‐System / GV ‐ VMS
to a server

Suitable for businesses or franchise stores: usually accompanied with a large cluster of networked GV ‐System / GV ‐VMS inuse and
an enormous amount of surveillance service required

Streamlines networking processes: no single server will be overwhelmed from GV ‐System / GV ‐ VMS to GV ‐Center V2 servers

GV ‐DISPATCH SERVER FEATURES

Create, edit groups of GV ‐Center V2 servers and subscribers

Up to 50 GV ‐Center V2 servers and 25,000 GV ‐System / GV ‐ VMS subscribers manageable

Network Load Balancing: Distribute GV ‐System requests to GV ‐Center V2 servers by Group or by least connections available

Direct GV ‐Center V2 servers to GV ‐Dispatch server available

View real ‐time GV ‐Center V2 events and attached videos

Check, control GV ‐Center V2 online/offline status

View subscriber's address book and single ‐view Camera/Audio Control Panel

Control PTZ, play videos, and two ‐way audio via Camera/Audio Control Panel

Automatic connection recovery

SEARCH/PLAYBACK

Keep tracks of GV ‐Center V2 event logs and Dispatch logs

Recycle feature: Delete old files for non ‐stop recording

Search GV ‐Center V2 events by types, GV ‐Center V2 ID, event date, and time

Remote playback events with video attachments

Flag bookmarks for the highlight of important events

GV-Dispatch Server August 1, 2017
-1-

LOG BROWSER

Display GV ‐Dispatch Servers status for system service, GV ‐Center V2 login/logout history, connection, control, and Dispatch
status

Backup event lists and video files

Log Filter as a search engine

GV ‐Dispatch Server Specifications
Features GV ‐Dispatch Server

Maximum # of Channels 400,000

Maximum # of Subscribers 25,000

Maximum # of Center V2 50

Maximum # of Sensors / Alarms 3,600,000 / 3,600,000

Real ‐Time Audio Monitoring Yes

Remote PTZ Control Yes

Remote I/O Control No

Auto Recording No

Event List Viewer Yes

Event List Filter Yes

Dual Monitor Support No

Network Load Support Yes

Automatic Connection Recovery Yes

Supported Language
Arabic, Bulgarian, Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hebrew,
Hungarian, Indonesian, Italian, Japanese, Lithuanian, Norwegian, Persian, Polish, Portuguese,
Romanian, Russian, Serbian, Simplified Chinese, Slovakian, Slovenian, Spanish, Swedish, Thai,
Traditional Chinese, Turkish

Minimum System Requirements
Standard Version Requirements
32‐bit
Windows 7 / 8 / 8.1 / 10 / Server 2008
OS
64‐bit
Windows 7 / 8 / 8.1 / 10 / Server 2008 / Server 2012 R2
CPU
Pentium 4, 3.0 GHz with HT
Memory
2 x 512 MB Dual Channels
Hard Disk
1 GB
Graphic Card
PCI ‐Express, 800 x 600 (1280 x 1024 recommended), 32 ‐bit color
Direct X
9.0c
Hardware
Internal or External GV ‐USB Dongle
Software
.Net Framework 3.5 SP1 and Chart Control
Advanced Requirements (Connects to 100 DVR subscribers or more)

32‐bit
Windows 7 / 8 / 8.1 / 10 / Server 2008
OS
64‐bit
Windows 7 / 8 / 8.1 / 10 / Server 2008 / Server 2012 R2
CPU
Core2 Duo E6600, 2.4 GHz
Memory
2 x 1 GB Dual Channels
Hard Disk
1 GB
Graphic Card
PCI ‐Express, 800 x 600 (1280 x 1024 recommended), 32 ‐bit color
Direct X
9.0c
Hardware
Internal or External GV ‐USB Dongle
Software
.Net Framework SP1 and Chart Control
Note: If you want to perform GPU decoding, refer to the GPU Decoding Specifications

GV-Dispatch Server August 1, 2017
-2-

GV-Dispatch Server August 1, 2017
-3-
GPU Decoding Specifications
A higher total frame rate can be achieved if your CPU or external VGA supports GPU decoding.
On ‐board VGA : GPU decoding is only supported when using the following Intel chipsets:
For H.264 Video Compression
* 2nd Generation Intel Core i3 / i5 / i7 Desktop Processors (Sandy Bridge) ‐ only support 1 MP to 2 MP videos
* 3rd Generation Intel Core i3 / i5 / i7 Desktop Processors (Ivy Bridge)
* 4th Generation Intel Core i3 / i5 / i7 Desktop Processors (Haswell / Haswell Refresh)
* 6th Generation Intel Core i3 / i5 / i7 Desktop Processors (Skylake)
* 7th Generation Intel Core i3 / i5 / i7 Desktop Processors (Kaby lake)

For H.265 Video Compression
* 6th Generation Intel Core i3 / i5 / i7 Desktop Processors (Skylake)
* 7th Generation Intel Core i3 / i5 / i7 Desktop Processors (Kaby lake)
External VGA : GPU decoding is only supported when using NVIDIA graphics cards with compute capability 3.0 or above and memory 2 GB
or above. To look up the commute capability of the NVIDIA graphics cards, refer to: https://developer.nvidia.com/cuda ‐ gpus .
Note: NVIDIA graphic cards do not support H.265 GPU decoding.
On ‐board VGA + external VGA : To have both the on ‐board VGA and external VGA perform GPU decoding, the VGAs must follow their
respective specifications listed above.
Note:
1. If you have both on ‐board VGA and external VGA installed, the on ‐board VGA must be connected to a monitor for H.264 / H.265 GPU
decoding.
2. You can install multiple external graphics cards if needed.

Software License
Free License N/A
Maximum License 50 Center V2 servers, 25000 subscribers from Center V2 servers
Increment for Each License N/A
Optional Combinations
1. Dispatch
2. Dispatch + Vital Sign Monitor
Dongle Type Internal or external
Note: It is recommended to use the internal GV ‐ USB Dongle to have the Hardware Watchdog function which restarts the PC when
Windows crashes or freezes.

Options
Optional Devices
Description
Internal USB Dongle
The USB dongle can provide the Hardware Watchdog function to the GV ‐Dispatch Servers by
restarting the computer when Windows crashes. You need to connect the dongle internally on the
motherboard.
