GV-ASManager

Introduction  GV ‐ASManager offers a network access control solution suitable for both small business and multinationals with facilities around the globe.  GV ‐ASManager can control up to 1000 units of GV ‐ AS / GV ‐ EV Controllers. In addition, IP devices can be connected to GV ‐ASManager through network to  rovide live video an d event associated playback. p      KEY FEATURES  Access Control Functions  * Control up to 1000 GV ‐ AS / GV ‐ EV Controllers  * Four access mode options: Card only mode, Card and PIN Code mode, Card or Common  mode, Release ...

Warranty: 36 mon.

Datasheet

Text contents of PDF datasheet:

Introduction
GV ‐ASManager offers a network access control solution suitable for both small business and multinationals with facilities around the globe.
GV ‐ASManager can control up to 1000 units of GV ‐ AS / GV ‐ EV Controllers. In addition, IP devices can be connected to GV ‐ASManager through network to
rovide live video an d event associated playback. p


KEY FEATURES
Access Control Functions
* Control up to 1000 GV ‐ AS / GV ‐ EV Controllers
* Four access mode options: Card only mode, Card and PIN Code mode, Card or Common
mode, Release mode
* Alarm conditions: door held open, door forced entry, tamper, access denied, duress, fire
alarm
* SMS or E ‐ Mail notification with user ‐defined content, video snapshot and user photo
* Up to 100 Web browser connections
* Up to 100000 cards for GV ‐ AS 21 / 41 / 81 series Controllers
* Up to 1000 system users and 10000 access groups
* Up to 256 time zones and weekly schedules
* Holiday planning for 14 months
* Multiple cards per user
* Enroll cards in batch mode
* Anti ‐Duress operation
* Anti ‐Passback capabilities
* Door Interlock
* Support Microsoft Access, SQL database and Active Directory database
* Import/export of card and user data in Access or Excel file format
* User ‐defined screen layout and dual monitor display support
* Patrol Tour that requires security personnel to check in at the specified locations
* Vehicle hotlist to help locate stolen vehicles or other vehicles of interest
* Languages supported: English, French, Hebrew, Japanese, Portuguese, Russian, Serbian,
Spanish, Traditional Chinese, Turkish

Video Integration
* Integrating video from GeoVision IP devices (GV ‐System, GV ‐VMS, GV ‐Video Server,
GV ‐Compact DVR, GV ‐ IP Camera) and third ‐party IP cameras
* Support for connecting to third ‐party IP devices using ONVIF, PSIA and RTSP protocols
* User ‐defined matrix of 16‐channel multi ‐views
* Click on events to play back recordings immediately

GV ‐ASRemote
* Monitor unlimited GV ‐ASManagers over the Internet


GV ‐ASManager
Installed in local PC, link to controllers
Main function: Management & Monitoring



GV ‐ASRemote
Installed in remote PC,
unlimited link to GV ‐ASManager
Main function: Monitoring & Basic control
GV-ASManager February 7, 2018
-1-

* Remote door monitoring, video playback, door operation

GV ‐TAWeb
* Flexible workforce schedule arrangement
* Payroll calculation
* Attendance and payroll report search

GV ‐ASWeb
* Remotely watch live view from connected devices
* Remotely add or delete cards, users, controllers, access groups, cameras
* Remotely set up operator accounts, patrol tours, parking lots, and notification settings
* Web interface for historical log search with corresponding video and snapshot
* Log export in Excel, Text, HTML, Zip and PDF file formats
* View access data on Google Maps in the order of access time
* Track GPS positions of detected vehicles

GV ‐VMWeb
* Web interface for creating visitor database and granting access
* Visitor record search
* Visitor self registration

GV ‐Access Mobile Applications
* Access up to 5 GV ‐ASManager systems from iOS and Android mobile devices
* Watch live view from cameras associated with a door or lane
* Lock or unlock a door
* Check door status to see if any alarm events have occurred at a door
* Open LPR lanes


GV ‐ASWeb
Web interface
Main function: Search historical event with
synchronized vide o


GV ‐Access Mobile Applications
Main function:
Remote control and monitoring

Minimum System Requirements
32‐bit
Windows 7 / 8 / 8.1 / 10 / Server 2008
OS
64‐bit
Windows 7 / 8 / 8.1 / 10 / Server 2008 R2 / Server 2012 R2
CPU Core 2 Duo E8400, 3.0 GHz

Memory 2 x 1 GB Dual Channels

Hard Disk 500 GB

VGA PCI ‐Express, 1280 x 1024 , 32‐bit color and support DirectX 10

DirectX End ‐ User Runtimes (November 2008)

Software
.NET Framework 3.5
SQL Server 2005 Express (optional)

Browser Internet Explorer 9.0 or later

Note : GV ‐ASManager has ended support for Windows XP and Vista .

Software License
Free License 4 controllers

Maximum License 1000 controllers

Increment for Each License 1 controller

Dongle Type External or internal

Note: The Maximum License is a paid service.


Supported Software Versions
GV ‐ DVR / NVR
GV ‐ASManager 4.2.1 – 4.2.3: V8.5.9.0
GV ‐ASManager 4.3: V8.6.0.0
GV ‐ASManager 4.3.5 – 4.4: V8.6.2.0
GV ‐ASManager 4.4.1: V8.6.2.0 or V8.7.0.0
GV ‐ASManager 4.4.2: V8.7.0.0 or V8.7.1.0
GV ‐ASManager 4.4.3: V8.7.1.0
GV ‐ASManager 5.0: V8.7.1.0
GV ‐ASManager 5.0.1.0 – 5.0.2.0: V8.7.3.0

GV-ASManager February 7, 2018
-2-





GV ‐ VMS
GV ‐ASManager 4.3.5 – 4.4.2: V15.10
GV ‐ASManager 4.4.2: V15.10 or V15.11
GV ‐ASManager 4.4.3: V15.11.3
GV ‐ASManager 5.0: V16.11.0.0
GV ‐ASManager 5.0.1.0 – 5.0.2.0: V16.11.0.0

N ote: GV ‐ASManager does not support 3rd party controllers.

Options
GV ‐FR2020
Face Re cognition Reader
Faces can be enrolled through a GV ‐FR2020 Face Recognition Reader and GV ‐ASManager will
synchronize the face data using TCP/IP connection.

GV ‐GF1911 Fingerprint
Reader
Fingerprints can be enrolled through a GV ‐GF1911 Fingerprint Reader installed on the computer of
the GV ‐ASManager. The fingerprint data are distributed through GV ‐ASManager to the assigned
fingerprint readers installed on GV ‐ AS / GV ‐ EV Controllers for access control.

GV ‐GF1921/GF1922
Fingerprint Reader
For local fingerprint enrollment, the user needs to register his or her fingerprints onsite using a
reader connected with GV ‐ASManager. For remote fingerprint enrollment, empty fingerprints can
be created on the GV ‐ASManager first, and the user can register his or her fingerprints later at a
GV ‐ GF1921 / 1922 with the assigned card.

GV ‐ IO Box
The GV ‐ IO Box provides 4, 8 or 16 inputs and relay outputs. It supports both DC and AC output
voltages, and provides a USB port for PC connection.

GV ‐PCR310 Enrollment
Reader
The GV ‐PCR310 is a USB card reader designed to assist with card enrollment to GV ‐ASManager /
GV ‐ ASWeb. It reads and transfers the identification data of a detected card to GV ‐ASManager /
GV ‐ ASWeb. The user can conveniently establish user accounts on GV ‐ ASManager / GV ‐ AS Web by
inserting the cards in the GV ‐ PCR310 Enrollment Reader.


CASE STUDY


Along with powerful access controllers and other hardware accessories, GeoVision offers a series of complementary access control software including
the GV ‐ASManager, GV ‐ASWeb, GV ‐ASRemote, and GV ‐Access mobile applications to provide the flexibility and scalability for both local and remote
access control.

The diagram above shows how the acce ss control software can be set up for a retail chain. GV ‐ASManager can be installed in local PCs of the chain stores
and the headquarters can remotely monitor the chain stores using GV ‐ASWeb or GV ‐ASRemote. Using GV ‐Access mobile applications, up to 5
GV ‐ASManager systems can be a ccessed from a mobile device.
