DS-7208HUHI-F2/N
Description
Input and Transmission Long distance transmission over twisted-pair cable & coax cable Compression H.264+ compression improves encoding efficiency by up to 50% and reduces data storage costs Output HDMI output at up to 4K (3840 x 2160) resolution (DS-7208HUHI-F2/N and DS-7216HUHI-F2/N) CVBS output improves compatibility at the most possibility Storage Two SATA interfaces (up to 6TB of capacity per HDD) HDD quota and group management for flexible recording storage 4/8/16-ch synchronous playback Smart search for efficient playback Supports the 3 rd party cloud storage (Dropbox/Google Drive/Microsoft OneDrive) Smart Function Supports multiple VCA(Video Content Analytics) events for both analog and smart IP cameras VQD(Video Quality Diagnostics) Network & Ethernet Access Hik Cloud P2P & HiDDNS (Dynamic Domain Name System) for easy network management Gigabit ...
Warning! Product withdrawn from production!
Warranty: 36 mon.
Datasheet
Text contents of PDF datasheet:
Input and Transmission
Long distance transmission over twisted-pair cable & coax cable
Compression
H.264+ compression improves encoding efficiency by up to 50% and reduces data storage costs
Output
HDMI output at up to
4K (3840 x 2160)
resolution (DS-7208HUHI-F2/N and DS-7216HUHI-F2/N)
CVBS output improves compatibility at the most possibility
Storage
Two
SATA interfaces
(up to 6TB of capacity per HDD)
HDD quota and group management for flexible recording storage
4/8/16-ch synchronous playback
Smart search for efficient playback
Supports the
3
rd
party cloud storage (Dropbox/Google Drive/Microsoft OneDrive)
Smart Function
Supports
multiple VCA(Video Content Analytics) events for both analog and smart IP cameras
VQD(Video Quality Diagnostics)
Network & Ethernet Access
Hik Cloud P2P & HiDDNS (Dynamic Domain Name System) for easy network management
Gigabit Ethernet network interface
(DS-7208HUHI-F2/N and DS-7216HUHI-F2/N)
Features and Functions
DS-7200HUHI-F2/N series
Standard Network Storage
Model
DS-7204HUHI-F2/N
DS-7208HUHI-F2/N
DS-7216HUHI-F2/N
H.264+/H.264
4-ch
8-ch
16-ch
BNC interface (1.0Vp- , supporting coaxitron connection
1080p/25Hz, 1080p/30Hz, 720p/25Hz, 720p/30Hz, 720P/50Hz, 720p/60Hz, 3MP
720p/25Hz, 720p/30Hz
CVBS input
Support
IP video input
2-ch
Up to 4
MP
resolution
Audio
compression
G.711u
Audio input
4-ch, RCA (2.0 Vp- K
CVBS output
Support
HDMI/VGA
output
VGA: 1-ch, 1920 x 1080/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60 Hz
HDMI: 1-ch, 1920 x 1080/60Hz,
1280 x 1024/60Hz,
1280 x
720/60Hz, 1024 x 768/60Hz
HDMI: 1-ch, 4K
(3840 x 2160)/30Hz, 2K
(2560 x 1440)/60Hz,
1920 x 1080/60Hz, 1280 x 1024/60Hz,
1280 x 720/60Hz,
1024 x 768/60Hz
Encoding
resolution
3MP@15fps/1080p/720p/WD1/4CIF/VGA/CIF
Frame rate
Main stream: 25
fps
(P)/30
fps
(N)
Sub-stream:
WD1/4CIF@12fps
(non-real-time);
CIF/QVGA/QCIF
(real time)
Video bitrate
32 Kbps to 10
Mbps
Audio output
1-ch, RCA (Linear, 1 K
Audio bit rate
64 Kbps
Dual-stream
Support
Stream type
Video, Video & Audio
Synchronous
playback
4-ch
8-ch
16-ch
Network
management
Remote
connections
128
Network
protocols
TCP/IP, PPPoE, DHCP, Hik
Cloud P2P, DNS DDNS NTP SADP NFS SCSI UPP , HTTPS,
ONVIF
Hard disk
SATA
2
SATA interfaces
Capacity
Up to 6TB capacity
External
interface
Two-way audio
input
1-ch, RCA (2.0 Vp- K
Network
interface
1, RJ45 10M/100M
self-adaptive Ethernet interface
1, RJ45 10M/100M/1000M
self-adaptive Ethernet interface
USB interface
2
x USB
2.0
Front panel: 1x USB 2.0
Rear panel: 1xUSB 3.0
Serial interface
1; RS-485 serial interface, half-duplex
Alarm in/out
4/1
8/4
16/4
General
Power supply
12 VDC
Consumption
(without HDD)
A
15W
A
20W
A
20W
Working
temperature
-10 ºC to +55 ºC
(14 ºF to
131 ºF)
Working
humidity
10% to
90%
Dimensions
(W x D x H)
380
x 320
x 48
mm (15.0
x
12.6
x
1.9
inch)
Weight
(without HDD)
A
1.5 kg (3.3 lb)
A
2 kg (4.4 lb)
A
2 kg (4.4 lb)
Specifications
Compression
Input
Input
Output
AHD input
HD input
