DS-3E0526P-E/M

DS-3E0526P-E/M  24-Port Gigabit Unmanaged PoE Switch    DS-3E0526P-E/M switch is a layer 2 PoE network switch,  providing 24 x Gigabit PoE ports and 2 x Gigabit SFP fiber  optical ports. On top of high-performance access, the switch  provides advanced PoE power technology to guarantee the  stable network upload of the adaptive data.        Feature and Function  • 24 x Gigabit PoE ports, 2 x Gigabit SFP fiber optical ports.  • IEEE 802.3at/af standard.  • IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, and IEEE 802.3z standard.  • 6 KV surge protection for PoE ports.  • PoE power management.  • Gigabit network access.  • Wire-speed forwarding.  • Store-and-forward switching.  • Solid high-strength metal shell.                                  Specification  Model DS-3E0526P-E/M  Network  parameters  Port number 24 x Gigabit PoE ports, 2 x Gigabit SFP fiber optical ports  Port type RJ45 port, full duplex, MDI/MDI-X adaptive  Standard IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, IEEE 802.3z  Forwarding mode Store-and-forward switching  MAC address table 8 K  Switching capacity 52 Gbps...

Warranty: 36 mon.

Datasheet

Text contents of PDF datasheet:

DS-3E0526P-E/M
24-Port Gigabit Unmanaged PoE Switch

DS-3E0526P-E/M switch is a layer 2 PoE network switch,
providing 24 x Gigabit PoE ports and 2 x Gigabit SFP fiber
optical ports. On top of high-performance access, the switch
provides advanced PoE power technology to guarantee the
stable network upload of the adaptive data.



Feature and Function
• 24 x Gigabit PoE ports, 2 x Gigabit SFP fiber optical ports.
• IEEE 802.3at/af standard.
• IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, and IEEE 802.3z standard.
• 6 KV surge protection for PoE ports.
• PoE power management.
• Gigabit network access.
• Wire-speed forwarding.
• Store-and-forward switching.
• Solid high-strength metal shell.
















Specification
Model DS-3E0526P-E/M
Network
parameters
Port number 24 x Gigabit PoE ports, 2 x Gigabit SFP fiber optical ports
Port type RJ45 port, full duplex, MDI/MDI-X adaptive
Standard IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, IEEE 802.3z
Forwarding mode Store-and-forward switching
MAC address table 8 K
Switching capacity 52 Gbps
Packet forwarding rate 38.688 Mpps
Internal cache 4.1 Mbits
PoE power
supply
PoE standard IEEE 802.3af, IEEE 802.3at
PoE power pin Ethernet cable 1/2/3/6 provide power supply.
PoE port Ports 1 to 24
Max. port power 30 W
PoE power budget 225 W
Max. power consumption 250 W
General
Shell Metal material with a fan equipped.
Net weight 2.920 kg (6.44 lb)
Gross weight 4.120 kg (9.08 lb)
Dimension (L x H x D) 440 mm x 44 mm x 220.8 mm (17.3” x 1.7” x 8.7”)
Operating temperature -10 °C to 55 °C (14 °F to 131 °F)
Storage temperature -40 °C to 85 °C (-40 °F to 185 °F)
Operating humidity 5% to 95% (no condensation)
Storage humidity 5% to 95% (no condensation)
Power supply 100 to 240 VAC, 50/60 Hz, 4 A (Max)
Power consumption in idle 25 W



Physical Interface
Front panel:

Back panel:


Available Model
DS-3E0526P-E/M

Optional Accessory
SFP Module Fiber type Connector Date Rate Wavelength Distance
HK-SFP-1.25G-20-1310
Single fiber,
Single-mode
LC 1250 Mbps Tx1310nm/Rx1550nm 0 to 20 km
HK-SFP-1.25G-20-1550
Single fiber,
Single-mode
LC 1250 Mbps Tx1550nm/Rx1310nm 0 to 20 km
HK-SFP-1.25G-1310-DF-MM
Duplex fiber,
Multi-mode
LC 1250 Mbps Tx1310nm/Rx1310nm 0 to 1 km
HK-SFP-1.25G-20-1310-DF
Duplex fiber,
Single-mode
LC 1250 Mbps Tx1310nm/Rx1310nm 0 to 20 km



HK-SFP-1.25G-20-1310 has to work with HK-SFP-1.25G-20-1550 as a pair.





Dimension (unit: mm)








Typical Application
