DS-2CV2U32G1-IDW

Availability: 0

Price: €128.71 128.71

excl. 23.00% TAX, excl. shipping costs

quantity szt.

product unavailable

add to wish list

Vendor:

Product code: 311304622

ask about product or pricing

Description

Warning! Product withdrawn from production!

Warranty: 36 mon.

Datasheet

Text contents of PDF datasheet:

DS-2CV2U32G1-IDW
3 MP 180° Wide Angle EXIR Cube Network Camera
* 2304 x 1296@20fps
* 180° Horizontal FOV
* H.265+, H.265
* Built-in Micro SD/SDHC/SDXC slot, up to 128G
* IR: Up to 10 m
* Built-in Wi-Fi
* Mobile monitoring via Hik-Connect app
* Built-in microphone and speaker, two-way audio
Key Features

Specifications
Camera
Image Sensor 1/3" Progressive Scan CMOS
Min. Illumination
Color: 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR,
Color: 0.028Lux @ (F2.0, AGC ON), 0 Lux with IR
Shutter Speed 1/3 s to 1/100,000 s
Slow Shutter Yes
Day & Night IR Cut Filter
Digital Noise Reduction 3D DNR
WDR 120dB
3-Axis Adjustment Pan: 0° to 360°, tilt: -75° to 65°, rotate: 0° to 360°
Lens
Focal length 1.68 mm
Aperture F2.0
FOV Horizontal field of view: 180°, Vertical field of view: 85°
Lens Mount M12
IR
IR Range Up to 10 m
Wavelength 850nm
Compression Standard
Video Compression
Main stream: H.265/H.264
Sub stream: H.265/H.264/MJPEG
H.264 Type Main Profile/High Profile
H.264+ Yes
H.265 Type Main Profile
H.265+ Yes
Video Bit Rate 32 Kbps to 8 Mbps
Audio Compression G722.1/G711ulaw/G711alaw/G726/MP2L2/PCM
Audio Bit Rate 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)
Smart Feature-set
Region of Interest Support 1 fixed region for main stream and sub-stream separately
Max. Resolution 2304 x 1296
Main Stream
50Hz: 20fps (2304 x 1296), 25fps (1920 x 1080, 1280 x 720)
60Hz: 20fps (2304 x 1296), 30fps (1920 x 1080, 1280 x 720)
Sub Stream
50Hz: 25fps(640 x 360, 480 x 272, 432 x 240)
60Hz: 30fps(640 x 360, 480 x 272, 432 x 240)
Image Setting Saturation, brightness, contrast, sharpness adjustable by client software or web browser
Image Enhancement BLC/3D DNR
Day/Night Switch Auto/Schedule
Network
Network Storage Support Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
Alarm Trigger
Motion detection, video tampering, network disconnected, IP address conflict, HDD full, HDD error,
illegal login
Protocols TCP/IP, ICMP, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP™, IGMP, QoS, IPv6

General Function One-key reset, anti-flicker, dual streams, heartbeat, password protection, privacy mask, watermark
API ONVIF (PROFILE S, PROFILE G), ISAPI
Simultaneous Live View Up to 6 channels
User/Host
Up to 32 users
3 levels: Administrator, Operator and User
Client iVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500
Interface
Audio 1 built-in mic, 1 built-in speaker, two-way audio, mono sound
On-board storage Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
Reset Yes
SVC Support H.264 and H.265 encoding
Wi-Fi
Wireless Standards IEEE 802.11b/g/n
Frequency Range 2.412 GHz to 2.4835 GHz
Channel Bandwidth 20M/40M
Protocols
802.11b: DQPSK, DBPSK, CCK
802.11g/n: OFDM/64-QAM, 16-QAM, QPSK, BPSK
Security WPA, WPA2
Transfer Rates 11b: 11Mbps, 11g: 54Mbps, 11n: up to 150Mbps
Wireless Range Up to 50 m
Audio
Environment Noise Filtering Yes
Audio Sampling Rate 16 kHz, 32kHz, 44.1kHz, 48kHz
General
Operating Conditions -10 °C to +40 °C (14°F to +104 °F), Humidity 95% or less (non-condensing)
Power Supply 5 VDC ± 10%, micro USB
Power Consumption and
Current
5 VDC, 1A, max. 6.5W
Material Bracket: metal, camera shell: plastic
Dimensions Φ76 mm x 105 mm (Φ3" x 4.1")
Weight Camera: Approx. 230 g (0.51 lb.)
Available Model:
DS-2CV2U32G1-IDW

11.6(0.5")
65.5(2.6")
29.8(1.2")
35.5(1.4")
Φ74.6(2.9")
105(4.1")
Φ76(3")

Dimensions
