DS-2CE56D0T-VPIR3E(2.8-12mm)

DS-2CE56D0T-VPIR3E  2 MP Vandal Proof PoC Dome Camera    * 2 MP high performance CMOS  * 1920 x 1080 resolution  * 2.8 mm to 12 mm vari-focal lens  * Ture Day/Night  * Up to 40 m IR distance  * PoC.af  * IP66, IK10  * Up the coax (HIKVISION-C)  Key Features                        Specifications          Camera  Image Sensor 2 MP progressive scan CMOS  Signal System PAL/NTSC  Frame Rate  PAL: 1080p@25fps  NTSC: 1080p@30fps  Effective Pixels 1920 (H) x 1080 (V)  Min. illumination 0.01 Lux@(F1.2, AGC ON), 0 Lux with IR  Shutter Time  PAL: 1/25 s to 1/50, 000 s  NTSC: 1/30 s to 1/50, 000 s  Lens 2.8 mm to 12 mm  Horizontal Field of View 105.2 ° to 32.8 °  Lens Mount Φ14  Day & Night IR cut filter  Angle Adjustment Pan: 0° to 355°, Tilt: 0° to 75°, Rotation: 0° to 355°  Synchronization Internal synchronization  S/N Ratio > 62 dB  Interface  Video Output 1 HD analog output  General  Operating Conditions -40 °C to 60 °C (-40 °F to 140 °F), Humidity 90% or less (non-condensation)  Power Supply 12 VDC ±15%/PoC.af  Power Consumption Max. 4 W  Protection Level IP66, IK10  Materia...

Warning! Product withdrawn from production!

Warranty: 36 mon.

Datasheet

Text contents of PDF datasheet:

DS-2CE56D0T-VPIR3E
2 MP Vandal Proof PoC Dome Camera

* 2 MP high performance CMOS
* 1920 x 1080 resolution
* 2.8 mm to 12 mm vari-focal lens
* Ture Day/Night
* Up to 40 m IR distance
* PoC.af
* IP66, IK10
* Up the coax (HIKVISION-C)
Key Features











Specifications




Camera
Image Sensor 2 MP progressive scan CMOS
Signal System PAL/NTSC
Frame Rate
PAL: 1080p@25fps
NTSC: 1080p@30fps
Effective Pixels 1920 (H) x 1080 (V)
Min. illumination 0.01 Lux@(F1.2, AGC ON), 0 Lux with IR
Shutter Time
PAL: 1/25 s to 1/50, 000 s
NTSC: 1/30 s to 1/50, 000 s
Lens 2.8 mm to 12 mm
Horizontal Field of View 105.2 ° to 32.8 °
Lens Mount Φ14
Day & Night IR cut filter
Angle Adjustment Pan: 0° to 355°, Tilt: 0° to 75°, Rotation: 0° to 355°
Synchronization Internal synchronization
S/N Ratio > 62 dB
Interface
Video Output 1 HD analog output
General
Operating Conditions -40 °C to 60 °C (-40 °F to 140 °F), Humidity 90% or less (non-condensation)
Power Supply 12 VDC ±15%/PoC.af
Power Consumption Max. 4 W
Protection Level IP66, IK10
Material Metal
IR Range Up to 40 m
Dimensions Ø 145.3 x 124.2 mm (Φ 5.72" x 4.89")
Weight 1300 g (2.87 lb.)




Order Models
DS-2CE56D0T-VPIR3E
Dimension
4
6

m
m

(
1
.
8
'
'
)
83.5 mm (3.3'')
46 mm (1.8'')
8
3
.
5

m
m

(
3
.
3
'
'
)
Ø

1
4
5
.
2

m
m

(
7
.
1
'
'
)
1
2
4
.
1

m
m

(
4
.
9
'
'
)


Accessory

DS-1273ZJ-140
Wall Mounting Bracket

DS-1275ZJ-SUS
Vertical Pole Mounting Bracket

DS-1276ZJ-SUS
Corner Mounting Bracket

DS-1271ZJ-140
Pendant Mounting Bracket

DS-1273ZJ-140B
Wall Mounting Bracket

DS-1241ZJ
In-ceiling Mounting Bracket

DS-1240ZJ
Inclined Ceiling Mounting Bracket
