DS-2CE16D5T-IR(3.6mm)

DS-2CE16D5T-IR  HD1080P WDR IR Turret Camera    * 2 Megapixel high-performance CMOS  * Analog HD output, up to 1080P resolution  * True Day/Night  * OSD menu, 3D DNR, Smart IR  * True WDR, up to 120dB  * Up to 20m IR distance  * IP66 weatherproof  * Up the Coax(HIKVISION-C, Pelco-C protocol)    Key Features                    Specifications          Camera  Image Sensor 2MP CMOS Image Sensor  Signal System PAL/NTSC  Effective Pixels 1944(H)*1092(V)  Min. illumination 0.01 Lux @ (F1.2,AGC ON),0 Lux with IR  Shutter Time 1/25(1/30)s to 1/50,000s  Lens  3.6mm (6mm optional)  Angle of View: 82.6°(3.6mm), 54.4°(6mm)  Lens Mount M12  Day & Night ICR  Angle Adjustment Pan: 0 - 360°, Tilt: 0 - 180°, Rotation: 0 - 360°  Synchronization Internal synchronization  WDR 120dB  Video Frame Rate 1080p@25fps/1080p@30fps  HD Video Output 1 Analog HD output  CVBS Output 1Vp-p Composite Output(75Ω/BNC)  S/N Ratio ＞62dB  Menu  Scene Indoor, Outdoor, Indoor1, LOW-LIGHT  Camera ID On/off (15 characters, position programmable)  AGC Support  D/N Mode Color/BW/EXT  White Balance ATW/ AWC-SET/ Manual  Privac...

Warning! Product withdrawn from production!

Warranty: 36 mon.

Datasheet

Text contents of PDF datasheet:

DS-2CE16D5T-IR
HD1080P WDR IR Turret Camera

* 2 Megapixel high-performance CMOS
* Analog HD output, up to 1080P resolution
* True Day/Night
* OSD menu, 3D DNR, Smart IR
* True WDR, up to 120dB
* Up to 20m IR distance
* IP66 weatherproof
* Up the Coax(HIKVISION-C, Pelco-C protocol)

Key Features









Specifications




Camera
Image Sensor 2MP CMOS Image Sensor
Signal System PAL/NTSC
Effective Pixels 1944(H)*1092(V)
Min. illumination 0.01 Lux @ (F1.2,AGC ON),0 Lux with IR
Shutter Time 1/25(1/30)s to 1/50,000s
Lens
3.6mm (6mm optional)
Angle of View: 82.6°(3.6mm), 54.4°(6mm)
Lens Mount M12
Day & Night ICR
Angle Adjustment Pan: 0 - 360°, Tilt: 0 - 180°, Rotation: 0 - 360°
Synchronization Internal synchronization
WDR 120dB
Video Frame Rate 1080p@25fps/1080p@30fps
HD Video Output 1 Analog HD output
CVBS Output 1Vp-p Composite Output(75Ω/BNC)
S/N Ratio ＞62dB
Menu
Scene Indoor, Outdoor, Indoor1, LOW-LIGHT
Camera ID On/off (15 characters, position programmable)
AGC Support
D/N Mode Color/BW/EXT
White Balance ATW/ AWC-SET/ Manual
Privacy Mask On/Off, maximum 8 zones
Motion Detection On/Off, maximum 4 zones
BLC Support
Anti-flicker On/off
Language
English, Japanese, CHN1, CHN2, Korean, German, French, Italian, Spanish, Polish, Russian, Portuguese,
Dutch, Turkish, Hebrew and Arabic
Functions
HSBLC, Digital noise reduction, Digital zoom(62x), Slow shutter, Mirror, Defog, Defect pixel correction,
SMART D-ZOOM
General
Operating Conditions -30 °C – 60 °C (-22 °F – 140 °F), Humidity 90% or less (non-condensing)
Power Supply 12 VDC±15%
Power Consumption Max. 4W
Protection Level IP66
IR Range Up to 20m
Communication Up the coax, Protocol: Pelco-C(CVBS output), HIKVISION-C(TVI output)
Dimensions Φ70x149.5 mm (Φ2.76” x5.89”)
Weight 360g (0.79 lb)




Dimensions

20150918
Accessories
unit:mm
154.5(6.08")
n54.7(2.15")
n70(2.76")
3- n4.2(0.17")
58.3(2.3")

Order Models
DS-2CE16D5T-IR



DS-1280ZJ-XS DS-1H18 X41T
Junction box Video Balun Camera Tester
