DS-2CD2A25G0/P-IZS(2.8-12mm)

Availability: 0

Price: $1,128.11 1128.11

excl. 23.00% TAX, excl. shipping costs

quantity szt.

product unavailable

add to wish list

Vendor:

Product code: 311313027

ask about product or pricing

Description

Warning! Product withdrawn from production!

Warranty: 36 mon.

Datasheet

Text contents of PDF datasheet:

DS-2CD2A 25G0/P-IS

2 MP VF Bulle t Network Ca me ra

* 1/ 1. 8” Progres si ve S can CM OS

* 192 0 x 1 080 @ 6 0fp s

* C olor : 0 .00 3 Lu x @ ( F1 .2 , A GC ON)
* H . 26 5 , H . 265 +, H .2 64 , H .2 64 +
* 140 dB WD R

* 3D DNR
* Ala rm I /O
* I P67 , I K10
* 1 RS-485 inte rfac e
* I R rang e u p to 40 m (2 .8 to 12 mm)
* Lic en se Pl ate R eco gn ition
* Supports alar ms fo r lis ted lic ens e plate in the
blac klis t and whit eli st
* Bu ilt-in micro SD/ SDH C /S DXC card s lot, up to 2 56
GB

Specifications
Camera
Image Sensor 1/1.8″ Progressive Scan CMOS
Min. Illumination Color: 0.003 Lux @ (F1.2, AGC ON), 0 Lux with IR
Shutter Speed 1 s to 1/100,000 s
Slow Shutter Yes
Day & Night IR Cut Filter
Digital Noise Reduction 3D DNR
WDR 140 dB
Angle Adjustment Bracket, pan: 0° to 355°, tilt: 0° to 90°, rotate: 0° to 360°
Lens
Focal length 2.8 to 12 mm
Aperture F1.2
Focus Auto, semi-auto, manual
FOV
2.8 to 12 mm: horizontal FOV 103.3° to 38.6°, vertical FOV 54.2° to 21.9°, diagonal FOV 124.2°
to 44.3°
Lens Mount Integrated
IR
IR Range 2.8 to 12 mm: up to 40 m
Wavelength 850 nm
Compression Standard
Video Compression
Main stream: H.265/H.264/H.265+/H.264+
Sub stream/third stream/fourth stream/fifth stream/custom stream: H.265/H.264/MJPEG
H.264 Type Baseline Profile/Main Profile/High Profile
H.264+ Main stream supports
H.265 Type Main Profile
H.265+ Main stream supports
Video Bit Rate 32 Kbps to 16 Mbps
Audio Compression No
Audio Bit Rate No
Smart Feature-set
Perimeter Protection Line crossing detection, intrusion detection
Exception Detection Scene change detection, defocus detection
Statistics No
Recognition License Plate Recognition
Region of Interest 4 fixed regions for main stream, sub stream, third stream and dynamic tracking
Road Traffic and Vehicle Detection
Accuracy
(Under recommended
installation and lighting
conditions)
Capture rate > 98%
Vehicle moving direction recognition accuracy > 96%
Mistaken capture rate < 2% (entrance/exit), < 5% (checkpoint)
Blacklist and whitelist Max. 10,000 records
No License Plate Detection Yes
Motorcycle LPR Yes (only applicable to checkpoint)

Max. Resolution 1920 x 1080
Main Stream
50Hz: 50fps (1920 x 1080, 1280 x 960, 1280 x 720)
60Hz: 60fps (1920 x 1080, 1280 x 960, 1280 x 720)
Sub Stream
50Hz: 25fps (704 x 576, 640 x 480)
60Hz: 30fps (704 x 480, 640 x 480)
Third Stream
50Hz: 25fps (1920 x 1080, 1280 x 960, 1280 x 720, 704 x 576, 640 x 480)
60Hz: 30fps (1920 x 1080, 1280 x 960, 1280 x 720, 704 x 480, 640 x 480)
Image Enhancement BLC, HLC, 3D DNR, Defog, EIS, lens distortion correction
Image Setting
Rotate mode, saturation, brightness, contrast, sharpness, AGC, and white balance are
adjustable by client software or web browser
Target Cropping Yes
SVC H.264 and H.265 encoding
Day/Night Switch Day/Night/Auto/Schedule/Triggered by Alarm In/ Triggered by video
Picture Overlay LOGO picture can be overlaid on video with 128 x 128 24bit bmp format
Network
Network Storage microSD/SDHC/SDXC card (256 GB), local storage and NAS (NFS, SMB/CIFS), ANR
Alarm Trigger
Motion detection, video tampering alarm, network disconnected, IP address conflict, illegal
login, HDD full, HDD error, alarm for listed license plate in the blacklist and whitelist
Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP,
SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
Security Measures
Password protection, HTTPS encryption, IEEE 802.1x port-based network access control, IP
address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest
authentication for ONVIF
General Function
One-key reset, anti-flicker, five streams and custom stream, heartbeat, password protection,
privacy mask, watermark, IP address filter
API ONVIF (PROFILE S, PROFILE G), ISAPI, SDK
Simultaneous Live View Up to 20 channels
User/Host Up to 32 users. 3 user levels: administrator, operator and user
Client iVMS-4200, Hik-Connect, iVMS-5200, Hik-Central
Web Browser
Plug-in required live view: IE8+, Chrome31.0-44, Mozilla Firefox30.0-51, Safari8.0+
Plug-in free live view: Chrome45+, Mozilla Firefox52+
Interface
Audio No
Communication Interface
1 RJ45 10M/100M/1000M Ethernet port,
1 RS-485 interface (half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
Alarm 2 inputs, 2 outputs (up to 24 VDC 1A or 110 VAC 500 mA)
Video Output 1Vp-p composite output (75 Ω/CVBS)
On-board storage Built-in micro SD/SDHC/SDXC slot, up to 256 GB
BNC CVBS analog output (4CIF resolution), internal
Reset Button Yes
Audio
Environment Noise Filtering No
Audio Sampling Rate No
General
Firmware Version 5.5.60
Operating Conditions
-30 °C to 60 °C (-22 °F to 140 °F), -H: -40 °C to 60 °C (-40 °F to 140 °F)
Humidity 95% or less (non-condensing)

* Listed resolutions are only selectable options. It does not mean that all streams can work at their maximum resolution at the same
time.
Available Model
DS-2CD2A25G0/P-IZS (2.8-12 mm)
Power Supply
12 VDC ± 20%, two-core terminal block
PoE (802.3at, class 4)
Power Consumption and
Current
-IZS: 12 VDC, 1.2 A, max. 14 W; PoE (802.3at, 42.5 V to 57 V), 0.4 A to 0.3 A
-IZHS: 12 VDC, 1.4 A, max. 16.5 W; PoE (802.3at, 42.5 V to 57 V), 0.4 A to 0.3 A
Protection Level IP67, IK10
Material Aluminum alloy
Dimensions
Camera: Φ140 x 351 mm (Φ5.5″ x 13.8″)
With package: 405 x 190 x 180 mm (15.9″ x 7.5″ x 7.1″)
Weight
Camera: approx. 2.5 kg (5.51 lb.)
With package: approx. 2.75 kg (6.06 lb.)

Dim e nsion

Ø140[5 .5]
99 [3. 9]
151 [5.9]
41 [1 .6 ]
351 [13.8]
236[9.3]

Unit: mm[inch]

Acce ssory

DS-1475ZJ-SUS
Ve rt ical Pol e Mo unt
DS-1476ZJ-SUS
C orner Mou nt
DS-2251ZJ
C olumn Mount
