DS-2AE7230TI-A

Key Features  Dimensions  Hikvision USA Inc.  Rev. 012815  Tel: 909.895.0400, sales.usa@hikvision.comFor more information: www.hikvision.com  908 Canada Court  City of Industry, CA 91748  Accessories  Available Models  DS-2AE7230TI-A  1080p Analog IR PTZ Dome Camera  DS-2AE7230TI-A, 24 VAC, outdoor    Unit : mm     m n   i tt   ti m iit m   it   t Ut U ntin   i in   ntint itinin    ICR  Intelligen t  P ositioning    MAS K    DS-2AE7230TI-A  Camera  Image Sensor1/3" CMOS  Maximum Image Resolution1920 x 1080  Signal SystemNTSC  Minimum IlluminationColor: 0.02 lux @ (f/1.6, AGC on); B/W: 0.002 lux @ (f/1.6, AGC on), 0 lux with IR  White BalanceAuto/Manual/ATW/Indoor/Outdoor  AGCAuto/Manual  S/N Ratio≥ 50 dB  3D DNRSupported  Digital WDRSupported  EISNTSC: 1–1/10,000 sec.  Backlight CompensationSupported  Shutter Time16x  Day/NightIR cut filter  Digital ZoomAuto/Semiautomatic/Manual  Privacy Mask8, selectable color or mosaic  Focus ModelAuto/Semiautomatic/Manual  Lens  Focal Length4–120 mm, 30x  Zoom SpeedApproximately 3.0 sec. (optical wide–tele)  Angle of View58°–1.7° (wide–tele)  Minimum Working...

Warning! Product withdrawn from production!

Warranty: 36 mon.

Datasheet

Text contents of PDF datasheet:

Key Features
Dimensions
Hikvision USA Inc.
Rev. 012815
Tel: 909.895.0400, sales.usa@hikvision.comFor more information: www.hikvision.com
908 Canada Court
City of Industry, CA 91748
Accessories
Available Models
DS-2AE7230TI-A
1080p Analog IR PTZ Dome Camera
DS-2AE7230TI-A, 24 VAC, outdoor

Unit : mm

m n
i tt
ti m iit m
it
t Ut U ntin
i in
ntint itinin

ICR
Intelligen t
P ositioning

MAS K

DS-2AE7230TI-A
Camera
Image Sensor1/3" CMOS
Maximum Image Resolution1920 x 1080
Signal SystemNTSC
Minimum IlluminationColor: 0.02 lux @ (f/1.6, AGC on); B/W: 0.002 lux @ (f/1.6, AGC on), 0 lux with IR
White BalanceAuto/Manual/ATW/Indoor/Outdoor
AGCAuto/Manual
S/N Ratio≥ 50 dB
3D DNRSupported
Digital WDRSupported
EISNTSC: 1–1/10,000 sec.
Backlight CompensationSupported
Shutter Time16x
Day/NightIR cut filter
Digital ZoomAuto/Semiautomatic/Manual
Privacy Mask8, selectable color or mosaic
Focus ModelAuto/Semiautomatic/Manual
Lens
Focal Length4–120 mm, 30x
Zoom SpeedApproximately 3.0 sec. (optical wide–tele)
Angle of View58°–1.7° (wide–tele)
Minimum Working Distance10–1500 mm (wide–tele)
Aperture Rangef/1.6–f/4.4
Pan and Tilt
Pan/Tilt RangePan: 360° endless; tilt: -15°–90° (auto flip )
Pan/Tilt Speed
Pan manual speed: 0.1°–160°/sec., pan preset speed: 240°/sec.
Tilt manual speed: 0.1°–120°/sec., tilt preset speed: 200°/sec.
Proportional ZoomRotation speed can be adjusted automatically according to zoom multiples
Number of Presets256
Patrols8 patrols, up to 32 presets per patrol
Patterns4 patterns, with the total recording time not less than 10 minutes
Power-Off MemorySupported
Park ActionsPreset/patrol/pattern/pan/tilt/auto/random/frame/panorama scan
PTZ Position DisplayOn/off
Preset FreezingSupported
Scheduled TasksPreset/patrol/pattern/pan/tilt/auto/random/frame/panorama scan
RS-485 Communication
Diagnosis
Supported
Infrared
IR RangeUp to 120 m IR range
IR IntensityAutomatically adjusted, depending on the zoom ratio
Input/Output
Monitor OutputHD 1080p output, 1.0 V [p-p]/75Ω, NTSC composite, BNC
RS-485 InterfaceHalf-duplex mode; self-adaptive Hikvision, Pelco-P, Pelco-D protocol
UTC FunctionHIKVISION_C (need UTC controller)
General
Menu LanguageEnglish
Power 24 VAC, maximum 50 W
Working Temperature-30° C–65° C (-22° F–149° F) (outdoor dome)
Humidity90% or less non-condensing
Protection Levels
IP66
TVS 4,000 V lightning protection, surge protection, and voltage transient protection
Dimensions φ220x353.4 mm (φ8.66" x 13.91") (outdoor)
Weight (approximate)4.5 kg (9.92 Ibs.)
WMP-L
PMPCMP
RPM
JBP
